Renesas Smart Power Stage (SPS) modules have integrated high accuracy current and temperature monitors that can be fed back to the controller and doubler to complete a multiphase DC/DC system. They simplify design and increase performance by eliminating the DCR sensing network and associated thermal compensation.

产品选型表

    Processing table
    PLP
    Output Current (Max) [Rail 1] (A)
    Input Voltage (Min) (V)
    Input Voltage (Max) (V)
    Bias Voltage Range (V)
    Switching Frequency (KHz)
    Qualification Level
    Lead Count (#)
    Pkg. Type
    器件号
    ISL99227
    Smart Power Stage (SPS) Module with Integrated High Accuracy Current and Temperature Monitors    		 N/A 60 4.5 18 5 2 Standard 32 PQFN
    ISL99227B
    Smart Power Stage (SPS) Module with Integrated High Accuracy Current and Temperature Monitors    		 N/A 60 4.5 18 5 2 Standard 32 PQFN
    ISL99360
    Smart Power Stage (SPS) with Integrated High Accuracy Current and Temperature Monitors    		 2033 12月 60 3 16 3.135 - 3.465, 4.75 - 5.25 1.25 Standard 32 PQFN
    ISL99360B
    Smart Power Stage (SPS) with Integrated High Accuracy Current and Temperature Monitors    		 2033 12月 60 3 16 3.135 - 3.465, 4.75 - 5.25 1.25 Standard 32 PQFN
    ISL99380BR5935
    80A Smart Power Stage (SPS) Module with Integrated High Accuracy Current and Temperature Monitors    		 N/A 80 3 16 4.75 - 5.25, 3.135 - 3.465 1.25 Standard 39 PQFN
    ISL99380R5935
    80A Smart Power Stage (SPS) Module with Integrated High Accuracy Current and Temperature Monitors    		 N/A 80 3 16 4.75 - 5.25, 3.135 - 3.465 1.25 Standard 39 PQFN
    ISL99390BR5935
    90A Smart Power Stage (SPS) Module with Integrated High Accuracy Current and Temperature Monitors    		 N/A 90 3 16 4.75 - 5.25, 3.135 - 3.465 1.25 Standard 39 PQFN
    ISL99390R5935
    90A Smart Power Stage (SPS) Module with Integrated High Accuracy Current and Temperature Monitors    		 N/A 90 3 16 4.75 - 5.25, 3.135 - 3.465 1.25 Standard 39 PQFN
    ISL99392BR5935
    90A Smart Power Stage (SPS) Module with Integrated High Accuracy Current and Master or Individual Temperature Monitors    		 N/A 90 3 16 3.135 - 3.465 1.25 Standard 39 PQFN
    ISL99392R5935
    90A Smart Power Stage (SPS) Module with Integrated High Accuracy Current and Master or Individual Temperature Monitors    		 N/A 90 3 16 3.135 - 3.465 1.25 Standard 39 PQFN
    RAA221320
    20A Smart Power Stage (SPS) with Integrated High Accuracy Current and Temperature Monitors    		 N/A 20 3 16 3.135 - 3.465 1.5 Standard 25 PQFN
    RAA221340
    40A Smart Power Stage (SPS) with Integrated High Accuracy Current and Temperature Monitors    		 2033 12月 40 3 16 3.135 - 3.465 1.5 Standard 25 PQFN
