9UMS9633B

描述

Ultra Mobile PC/Mobile Internet Device

特性

• 3 - CPU low power differential push-pull pairs
• 3 - SRC low power differential push-pull pairs
• 1 - LCD100 SSCD low power differential push-pull pair
• 1 - DOT96 low power differential push-pull pair
• 1 - REF, 14.31818MHz, 3.3V SE output
• Supports Dothan ULV CPUs with 67 to 167 MHz CPU outputs
• Dedicated TEST/SEL and TEST/MODE pins saves isolation resistors on pins
• CPU STOP# input for power management
• Fully integrated Vreg
• Integrated series resistors on differential outputs
• 1.5V VDD IO operation, 3.3V VDD core and REF supply pin for REF
• Industrial Temperature (-40 to +85°C) version available

产品对比

应用
