描述
The TSI107 Host Bridge for PowerPC provides system interconnect between PowerPC processors, PCI peripherals, and local memory. The TSI107 provides many of the other necessities for embedded applications, including a high-performance memory controller and dual processor support; two-channel flexible DMA controller, an interrupt controller, an I2O-ready message unit, an inter-integrated circuit controller (I2C), and low-skew clock drivers.
特性
- Processor interface supports the PowerPC 603e/7xx and MPC74xx processors
- Processor bus frequency supports up to 133 MHz
- Memory interface supports a 64-bit data bus up to 133 MHz
- PCI interface support a 32-bit/66 MHz bus
- PCI arbiter supports up to five other PCI devices
- Embedded Programmable Interrupt Controller (EPIC)
- Two-channel integrated DMA Controller
- I2C Controller
- IEEE 1149.1 compliant, JTAG boundary-scan interface
- Available in commercial temperature range (0°C to 105°C junction temperature)
