The 5V41064 is a PCIe Gen2 compliant spread spectrum capable clock generator. The device has 1 differential HCSL output and can be used in communication or embedded systems to substantially reduce electro-magnetic interference (EMI). Spread spectrum can be enabled via a select pin.
特性
- 1 - 0.7V current mode differential HCSL output pairs
- 16-pin QFN package
- very small board footprint
- Spread-spectrum capable
- reduces EMI
- Outputs can be terminated to LVDS
- can drive a wider variety of devices
- Spread enable via pin selection
- no software required to configure device
- Industrial temperature range available
- supports demanding embedded applications
- For PCIe Gen3 applications, see the 5V41234
- Cycle-to-cycle jitter < 100 ps
- PCIe Gen2 phase jitter < 3.0ps RMS
