概览
描述
The ICS843011C is a Fibre Channel clock generator that uses a 26.5625MHz crystal to synthesize 106.25MHz or a 25MHz crystal to synthesize 100MHz. The ICS843011C has excellent <1ps phase jitter performance, over the 637kHz to 10MHz integration range. The device is packaged in a small 8-pin TSSOP, making it ideal for use in systems with limited board space.
特性
- One differential 3.3V LVPECL output
- Crystal oscillator interface designed for 26.5625MHz, 18pF parallel resonant crystal
- Output frequency: 106.25MHz or 100MHz
- VCO range: 560MHz to 680MHz
- RMS phase jitter at 100MHz, using a 25MHz crystal (637kHz to 10MHz): 0.29ps (typical)
- 3.3V operating supply
- 0 °C to 70 °C ambient operating temperature
- Available in lead-free (RoHS 6) packaging
产品对比
应用
设计和开发
模型
ECAD 模块
点击产品选项表中的 CAD 模型链接，查找 SamacSys 中的原理图符号、PCB 焊盘布局和 3D CAD 模型。如果符号和模型不可用，可直接在 SamacSys 请求该符号或模型。
