概览
描述
The HS4103 is a highly accurate, ultra-low power, fully calibrated relative humidity and temperature sensor. The MEMS sensor features a proprietary sensor-level protection ensuring high reliability and long-term stability. The HS4103 is fully calibrated and temperature compensated with an Analog ratio-metric output.
特性
- Humidity range: 0% to 100%RH
- RH accuracy: ±2.5%RH, typical
- 10% to 90% ratio-metric analog output
- Fast RH response time: 4 seconds, typical
- Temperature sensor accuracy: ±0.25°C, typical (0 to +70°C)
- Low current consumption: 0.92µA average (3.3V supply)
- Excellent stability against aging
产品对比
应用
文档
相关文档
请登录后开启订阅
|
|
|
|
|---|---|---|
| 类型 | 文档标题 | 日期 |
| 数据手册 | PDF 573 KB | |
| EOL 通告 | PDF 748 KB | |
| 应用笔记 | PDF 1.81 MB | |
| 应用笔记 | PDF 131 KB | |
| 产品变更通告 | PDF 368 KB | |
5 items
|
||
设计和开发
模型
ECAD 模块
点击产品选项表中的产品，查找 SamacSys 中的原理图符号、PCB 足迹和 3D CAD 模型。点击产品选项表中的产品，查找 SamacSys 中的原理图符号、PCB 足迹和 3D CAD 模型。
