The RTKA788000DE0000BU evaluation board allows for the measurement of power line currents up to 40A.

The board includes two RAA788000 current sensor ICs in an opposite sensor topology and a 1ft section of AWG-8 cable, for easy connection to a high-current source.

The output amplifiers of the two sensors are configured to a single differential amplifier to allow for differential current measurements with minimum noise.

特性

  • Two current sensor ICs
  • Gain setting of 1400V/V
  • Opposite sensor topology
  • Differential current measurement up to 40A
  • Wide 2.7V to 3.6V supply voltage range
