Analog Products

A critical part of most data acquisition systems, Renesas offers several sample and hold amplifiers for general-purpose and military and defense applications that include precision data acquisition systems, synchronous sampling, wide bandwidth analog-to-digital (A/D) conversion, auto-zero circuits, digital-to-analog (D/A) converter deglitching, peak detection, and high-speed DC restore.

产品选型表

    Processing table
    Bandwidth (MHz)
    VOS (mV)
    Slew Rate (V/µs)
    Droop Rate (μV/μs)
    Hold Step Error (mV)
    IBIAS (nA)
    IS (per amp) (mA)
    tACQ (ns)
    AVOL (dB)
    Requires External Hold Capacitor
    Lead Count (#)
    Pkg. Type
    器件号
    HA-2420/883
    3.2 Microsecond Sample and Hold Amplifiers    		 2.5 2 5 .005 10 40 3.5 3200 94 是的 14 CERDIP
    HA-5320
    1 Microsecond Precision Sample and Hold Amplifier    		 2 0.2 45 0.08 5 70 11 1000 126 是的 14, 16 CERDIP, SOICW
    HA-5330
    650ns Precision Sample and Hold Amplifier    		 4.5 0.2 90 0.01 0.5 20 19 650 146 否 20 CLCC
    HA5351
    64ns Sample and Hold Amplifier    		 40 1 105 0.3 1 2500 20 64 108 否 8 SOICN
