Dual/n-Phase Buck PWM Controller with Integrated Drivers Evaluation Board
The ISL8120EVAL3Z evaluation board is used for a performance demo of dual independent outputs and DDR applications.
The ISL8120 integrates two voltage-mode...
The ISL8120 integrates two voltage-mode PWM leading-edge modulation control, with input feed-forward synchronous buck PWM controllers, to control a dual independent voltage regulator or a 2-phase single output regulator. It also integrates current sharing control for the power module to operate in parallel, which offers high system flexibility. The ISL8120 integrates an internal linear regulator, which generates VCC from input rail for applications with only one single supply rail. The internal oscillator is adjustable from 150kHz to 1. 5MHz, and is able to synchronize to an external clock signal for frequency synchronization and phase paralleling applications. Its PLL circuit can output a phase-shift programmable clock signal for the system to be expanded to 3-, 4-, 6-, 12- phases with desired interleaving phase shift. The ISL8120’s Fault Hand Shake feature protects any channel from overloading/stressing due to system faults or phase failure. The undervoltage fault protection features are also designed to prevent a negative transient on the output voltage during falling down. This eliminates the Schottky diode that is used in some systems for protecting the load device from reversed output voltage damage.
Software title
|
Software type
|
公司
|
---|---|---|
iSim:PE 离线模拟工具 iSim Personal Edition(iSim:PE )可加快设计周期并降低项目早期风险,确定可用于当前和下一代设计的部件。
|
Simulator | 瑞萨电子 |
1 item
|
The ISL8120EVAL3Z evaluation board is used for a performance demo of dual independent outputs and DDR applications.
The ISL8120 integrates two voltage-mode...
The ISL8120EVAL4Z evaluation board is used for a performance demo of 2/n-phase single-output applications.
The ISL8120 integrates two voltage-mode synchronous buck...
