符合 AEC-Q100 汽产产准的 RL78/F1x 16 位微控制器，并具有超低功耗。其产大的产品产合，可自 8 到 512KB 产存 / 0.5 到 32 KB RAM，以及自 20 到 144 引脚（QFN、LQFP、SSOP 封装）产行产展，可产产最佳的产用需求覆盖率。其他主要功能包括最高 150°C 产境温度的高温支持（RL78 / F13 和 F14 可产），BLDC / FOC 产机控制，跨系列的 CAN、LIN、UART、CSI、I2C 接口及产硬件兼容性，以及广泛的生产系产。

此外，RL78/D1A 微控制器配产了多产四个步产产机产产器和一个支持多产 216 段的 LCD 控制器。

些产新的 MCU 是产产各种高可靠性汽产产行器和产感器以及产身和汽产产表区域中低端 ECU 的理想之产。

特色 RL78 MCU

These featured products are part of the Renesas Easy-to-Start MCU design, tool and documentation portal.

设计支持页面 产品系列 描述 用户手册
RL78/F13 RL78/F13 32MHz、高达 128KB ROM、8KB RAM、LIN、CAN、最低功耗、Ta=150°C pdf_icon_for_table.png
RL78/F14 RL78/F14 32MHz、高达 256KB ROM、20KB RAM、LIN、CAN、最低功耗、Ta=150°C pdf_icon_for_table.png
RL78/F15 RL78/F15 32MHz、高达 512KB ROM、32KB RAM、LIN、CAN、最低功耗 pdf_icon_for_table.png

汽车产品

产品选型表

    Processing table
    器件号
    Bit Size
    CPU
    Program Memory (KB)
    Data Flash (KB)
    RAM (KB)
    Lead Count (#)
    Supply Voltage (V)
    Operating Freq (Max) (MHz)
    RTC
    LVD
    DMA
    I/O Ports
    Timer
    ADC
    DAC
    CAN (ch)
    Ethernet
    USB
    PLP
    Pkg. Type
    Temp. Range
    RL78/D1A
    Microcontrollers for Automotive Low-end Instrument Clusters    		 16 RL78 24, 32, 48, 64, 96, 128, 256, 384, 512 8 24, 20, 16, 2, 3, 4, 6, 8 48, 64, 80, 100, 128 2.7 - 5.5 24, 32 是的 是的 Yes 38, 54, 68, 84, 112 16-bit x 24-ch 10-bit x 5-ch, 10-bit x 8-ch, 10-bit x 9-ch, 10-bit x 11-ch 1, 2 No N/A LQFP -40 to 85°C, -40 to 105°C
    RL78/F12
    Microcontrollers with Low Consumption Current for Automotive Applications    		 16 RL78 8, 16, 24, 32, 48, 64 4 1, 0.5, 1.5, 2, 3, 4 20, 30, 32, 48, 64 2.7 - 5.5, 1.8 - 5.5 32 否, 是的 是的 Yes 16, 26, 28, 44, 58 16-bit x 8-ch 10-bit x 4-ch, 10-bit x 8-ch, 10-bit x 10-ch, 10-bit x 12-ch No N/A HWQFN, LQFP, LSSOP -40 to 85°C, -40 to 125°C
    RL78/F13
    Microcontrollers with Low Consumption Current for Automotive Applications    		 16 RL78 16, 32, 48, 64, 96, 128 4 1, 2, 3, 4, 6, 8 20, 30, 32, 48, 64, 80 2.7 - 5.5 24, 32 是的 是的 Yes 13, 23, 25, 38, 52, 68 16-bit x 11-ch, 16-bit x 15-ch
    10-bit x 4-ch, 10-bit x 8-ch, 10-bit x 10-ch, 10-bit x 12-ch and more...
    		 1 No N/A HVQFN, LFQFP, LQFP, LSSOP -40 to 105°C, -40 to 125°C, -40 to 150°C
    RL78/F14
    Microcontrollers with Low Consumption Current for Automotive Applications    		 16 RL78 48, 64, 96, 128, 192, 256 4, 8 4, 8, 10, 16, 6, 20 30, 32, 48, 64, 80, 100 2.7 - 5.5 24, 32 是的 是的 Yes 23, 25, 38, 52, 68, 86 16-bit x 15-ch, 16-bit x 19-ch
    10-bit x 10-ch, 10-bit x 12-ch, 10-bit x 15-ch, 10-bit x 18-ch and more...
    		 8-bit x 1-ch 1 No N/A HVQFN, LQFP, LSSOP -40 to 105°C, -40 to 125°C, -40 to 150°C
    RL78/F15
    Microcontrollers with Enhanced CAN / LIN / IEBus and Memory Lineup for Automotive Applications    		 16 RL78 128, 192, 256, 384, 512 16, 8 26, 32, 16, 20, 10 48, 64, 80, 100, 144 2.7 - 5.5 24, 32 是的 是的 Yes 38, 52, 68, 86, 130 16-bit x 19-ch, 16-bit x 27-ch 10-bit x 18-ch, 10-bit x 20-ch, 10-bit x 25-ch, 10-bit x 31-ch 8-bit x 1-ch 2 No N/A HVQFN, LQFP -40 to 105°C, -40 to 125°C
    RL78/F23
    Next Gen. Actuator and Sensor Microcontroller    		 16 RL78 128 8 12 是的 是的 N/A
    RL78/F24
    Next Gen. Actuator and Sensor Microcontroller    		 16 RL78 256 16 24 32, 48, 64, 80, 100 2.7 - 5.5 40 是的 是的 Yes 25, 38, 52, 68, 86 16-bit x 19-ch
    12-bit x 10-ch, 12-bit x 19-ch, 12-bit x 24-ch, 12-bit x 25-ch and more...
    		 8-bit x 1-ch 1 No N/A -40 to 105°C, -40 to 125°C, -40 to 150°C
