Renesas S-RIO 2.1 转发器系列可提供各种顶部模拟性能、更低功耗和大多数系统级功能，来提高信号的完整性。 RapidIO 信号转发器（转接驱动器）已针对计算、存储和通信领域要求苛刻的 2.5Gbps 至 6.25Gbps 应用进行优化。

功能：

  • 4 或 8 通道 RapidIO 信号转发器 / 转接驱动器
  • 高级信号调节功能
  • 高级诊断功能
  • 高级节能功能
  • 可支持故障备份的内置复用器/解复用器
  • I2C 编程接口
  • 商业和工业温度

Download: IDT Signal Integrity Products Overview (PDF)

接口&连接

产品选型表

    Processing table
    器件号
    Channels (#)
    Protocol
    Data Rate Max (Gbps)
    Pkg. Code
    Pkg. Type
    长度 (mm)
    宽度 (mm)
    Temp. Grade
    89HP0608R
    S-RIO Signal Repeater    		 8 S-RIO 6.25 ABG100 CABGA 9 9 C, I
