Renesas 提供数控的中频 (IF) 和射频 (RF) 可变增益放大器 (VGA)，这些放大器采用了FlatNoise™技术，当增益降低时其噪声不会恶化。 Renesas 的低噪声器件提高了服务质量 (QoS)，降低了系统对数据转换器的信噪比 (SNR) 要求，从而降低了系统成本。

一部分Renesas 的数字电压增益放大器采用Glitch-Free 专利技术，其目的是将其最高有效位 (MSB) 转变过程中产生的瞬时“毛刺”最大程度减少 95%，来消除发送和/或接收链路中因衰减设置而引起的过冲（毛刺）。 对于蜂窝基站和其他无线基础设施设备中的接收机和发射机而言，Renesas 的 IF VGA 和 RF VGA 是理想选择。

关于可变增益放大器（RF VGA 或 DVGA）

您可以 把RF 系统中的可变增益放大器 (RF VGA) 简单的理解为放大器（增益器件）和衰减器集成在同一封装中。 我们将使用数控的放大器称作数字可变增益放大器 (DVGA)。 这种器件既用在在发射机中也用在接收机中，目的是在信号链路中增加可调增益器件，这些器件可通过增加或减小衰减值实现增益调节（大小增益场景均可）。

产品选型表

    Processing table
    Function
    Frequency Range (MHz)
    Supply Voltage (V)
    Pkg. Type
    Lead Count (#)
    Output IP3 (dBm)
    Gain (dB)
    Gain Resolution (dB)
    Noise Figure (dB)
    器件号
    F0440
    Dual Matched Broadband RF DVGA - 400MHz to 2700MHz    		 Dual RF DVGA 600 - 2700 4.75 - 5.25 VFQFPN 36 41 11.6 6
    F0443
    Dual Matched Broadband RF DVGA - 0.6GHz to 2.7GHz    		 Dual RF DVGA 600 - 2700 4.75 - 5.25 LGA 48 39 29.5 6
    F0448
    Dual Matched Broadband RF DVGA    		 RF DVGA 3400 - 3800 4.75 - 5.25 VFQFPN 36 37 13 1 6
    F0452B
    Dual Path RF Switch / LNA 2300MHz to 2700MHz    		 Switch / LNA 2300 - 2700 3.3 LGA 32 23 34 6 1.5
    F0452C
    Dual Path RF Switch / LNA DVGA - 2.3GHz to 2.7GHz    		 Switch / LNA 2300 - 2700 3.15 - 3.45 LGA 32 23 34
    F0453B
    Dual Path RF Switch / LNA 3300MHz to 4000MHz    		 Switch / LNA 3400 - 3800 3.3 LGA 32 23 34.5 6 1.35
    F0453C
    Dual Path RF Switch / LNA DVGA - 3.3GHz to 4.0GHz    		 Switch / LNA 3300 - 4000 3.15 - 3.45 LGA 32 23 35
    F0472B
    Dual Path RF Switch with LNA and DVGA - 2.3GHz to 2.7GHz    		 Switch / LNA 2300 - 2700 3.15 - 3.45 VFQFPN 32 24 34
    F0480
    Matched Broadband RF VGA with Glitch-Free and Zero-Distortion    		 RF VGA 400 - 2700 4.75 - 5.25 VFQFPN 32 41 23 1 4
    F0502
    Dual Path RF to IF Mixer - 600MHz to 1000MHz    		 Dual Path RF to IF Mixer 600 - 1000 4.75 - 5.25 VFQFPN 68 44 28
    F0552
    Dual Path RF to IF Mixer - 1700MHz to 2050MHz    		 Dual Path RF to IF Mixer 1700 - 2050 4.75 - 5.25 VFQFPN 68 46 28
    F0562
    Dual Path RF to IF Mixer - 2300MHz to 2700MHz    		 Dual Path RF to IF Mixer 2300 - 2700 4.75 - 5.25 VFQFPN 68 44 29
    F1200
    Low-noise Digital Intermediate Frequency Variable Gain Amplifier with FlatNoise™    		 IF VGA 30 - 150 4.75 - 5.25 VFQFPN 28 48 22 0.25 2.2
    F1240
    Low-noise Dual IF VGA with FlatNoise™    		 Dual IF VGA 10 - 500 4.75 - 5.25 VFQFPN 32 47 20 0.5 4
    F1241
    Low-noise Dual IF VGA with FlatNoise™    		 Dual IF VGA 10 - 500 4.75 - 5.25 VFQFPN 32 47 20 1 4
    F1280
    Dual VGA 0.001MHz to 1200MHz    		 VFQFPN 32
    F1431B
    High Linearity RF DVGA 0.35GHz to 3GHz    		 RF DVGA 350 - 3000 4.75 - 5.25 VFQFPN 24 41.1 14.3 0.5 4.2
    F1440
    500MHz to 1000MHz Configurable 50Ω or 100Ω DIFF-In to 50Ω SE-Out Variable Gain Amplifier    		 VFQFPN 32
    F1441
    1350MHz to 2800MHz Configurable 50Ω or 100Ω DIFF-In to 50Ω SE-Out Variable Gain Amplifier    		 VFQFPN 32
    F1451
    TX Digital VGA 450MHz to 1100MHz    		 TX VGA 700 - 1100 4.75 - 5.25 VFQFPN 28 41 32 0.5 3.6
    F1455
    TX RF VGA with KLIN™ Feature    		 TX VGA 1400 - 2300 4.75 - 5.25 VFQFPN 28 39 32.8 0.5 3.9
    F1456
    TX Digital VGA 2100 MHz to 2950 MHz    		 TX VGA 2100 - 2950 4.75 - 5.25 VFQFPN 28 38 32.1 0.5 3.9
    F159V
    Integrated TRx IC - 450MHz to 2800MHz    		 TRx IC 450 - 2800 3.3 VFQFPN 68 31 18.3
    F2480
    Broadband RF Analog VGA, 400MHz to 3000MHz    		 RF VGA 400 - 3000 4.75 - 5.25 VFQFPN 32 41.5 12 4.3
    F4481
    DIFF-In / SE-Out Quad Path TX DVGA - 400MHz to 1100MHz    		 Quad Tx DVGA 400 - 1100 3.3 LGA 56 35 28 0.5 5.7
    F4482
    DIFF-In / SE-Out Quad Path TX DVGA - 1300MHz to 2800MHz    		 Quad Tx DVGA 1300 - 2800 3.3 LGA 56 36.8 27.5 0.5 5.7
    Parametric Table tips

    Tips for Using This Parametric Table:

    • Hide Filters button in header: Collapse or expands filters
    • Column sort buttons in header: Sort Column alphabetically / numerically descending or ascending
    • Reset button in header: Reset all filters to the page default
    • Full Screen button in header: Expand the table to full screen view (user must close out of full screen before they can interact with rest of page)
    • Export button in header: Export the filtered results of the table to an Excel document
    • Filter parts search bar in header: Type to filter table results by part number
    • Hide column button in column headers: Select to hide columns in table
    • AND / OR toggle switches in header: Toggles the logic of this particular filter to be “AND” or “OR” logic for filtering results
    • Multiselect checkboxes at beginning of each row in table: Select these checkboxes to compare products against each other
    • Document icon next to product name in row: View the featured document for this product
    • Chip icon next to the right of the document icon in row: View the block diagram for this product
    • Cart icon to the right of the chip icon: Indicates that samples are available for this product
