概览

描述

This highly integrated solution supports the full Bluetooth® 4.2 features. As a SmartBond™ device, it offers the highest performance, lowest power consumption, and smallest footprint. Delivering processing capacity when you need it and saving power when you don’t, it can manage multi-sensor arrays and enable always-on sensing. Plus, our SmartSnippets™ tooling helps you optimize your software for power consumption.

The DA14680 System-on-Chip (SoC) includes Flash memory, offers unlimited execution space, and enables Over-the-Air (OTA) updates. With an integrated power management unit (PMU) that includes system power rails, a battery charger, and a fuel gauge, it supports rechargeable batteries natively and can power a complete wearable system. Meanwhile, a dedicated hardware crypto engine delivers banking-level security (including Apple HomeKit support) with end-to-end encryption to keep personal data safe.

Benefits

  • Processing power on-demand
  • Unlimited execution space
  • High-level security
  • PMU can power a complete wearable system
  • Advanced interfaces for voice commands and audio support
  • World-class radio performance
  • Sensor hub functionality
  • Optimized for flexibility, lowest power consumption, smallest footprint, and lowest system cost

Package

  • AQFN-60

特性

  • Bluetooth Low Energy (Bluetooth 4.2 specification)
  • Arm® Cortex®-M0 application processor
  • Flexible memory architecture: 8Mb Flash, 64kB One-Time-Programmable (OTP) memory, 128kB Data SRAM, 16kB Cache SRAM, 128kB ROM
  • Dedicated hardware crypto engine
  • Integrated battery and system PMU
  • Power supply 1.7V - 4.75V
  • Single pin RF I/O
  • Rich set of analog and digital peripherals

产品对比

应用

文档

设计和开发

软件与工具

软件下载

样例程序

样例程序

筛选
类型 文档标题 日期 日期
示例代码 ZIP 478 KB
示例代码 ZIP 1.35 MB
示例代码 ZIP 561 KB
示例代码 ZIP 687 KB
示例代码 ZIP 8.03 MB
示例代码 ZIP 12 KB
6 项目

开发板与套件

模型

ECAD 模块

点击产品选项表中的 CAD 模型链接,查找 SamacSys 中的原理图符号、PCB 焊盘布局和 3D CAD 模型。如果符号和模型不可用,可直接在 SamacSys 请求该符号或模型。

Diagram of ECAD Models

产品选项

当前筛选条件

支持

支持社区

支持社区

在线询问瑞萨电子工程社群的技术人员,快速获得技术支持。
浏览常见问题解答

常见问题

浏览我们的知识库,了解常见问题的解答。
提交工单

提交工单

需要咨询技术性问题或提供非公开信息吗?

支持社区

  1. DA14680 GPIO输出电平休眠后无法保持

    DA14680的P3_7外部未连接任何器件,软件配置如下: hw_gpio_configure_pin_power(HW_GPIO_PORT_3, HW_GPIO_PIN_7, HW_GPIO_POWER_V33); hw_gpio_configure_pin(HW_GPIO_PORT_3, HW_GPIO_PIN_7, HW_GPIO ...

    2017年12月18日
  2. DA14680和14681从Flash加载程序的操作兼容吗?

    Dialog: 你好! 我想购买DA14680的评估板,并使用片上Flash存储固件及需要掉电保存的数据,但官网只有DA14681的评估板。 如果使用DA14681+外部Flash ...

    2016年11月21日
  3. DA14680 GPIO输出电平休眠后无法保持

    DA14680的P3_7外部未连接任何器件,软件配置如下: hw_gpio_configure_pin_power(HW_GPIO_PORT_3, HW_GPIO_PIN_7, HW_GPIO_POWER_V33); hw_gpio_configure_pin(HW_GPIO_PORT_3, HW_GPIO_PIN_7, HW_GPIO ...

    2017年12月18日
查看所有来自 支持社区 的搜索结果 (39个)
