概览

描述

The HS4001 is a highly accurate, ultra-low power, fully calibrated relative humidity and temperature sensor. The MEMS sensor features a proprietary sensor-level protection ensuring high reliability and long-term stability. The HS4001 is fully calibrated and temperature compensated with an I2C digital output.

特性

  • Humidity range: 0% to 100%RH
  • RH accuracy: ±1.5%RH, typical
  • I2C digital output
  • 14-bit resolution
  • Fast RH response time: 4 seconds, typical
  • Temperature sensor accuracy: ±0.2°C, typical (-10°C to +80°C)
  • Low current consumption: 0.3µA average (8-bit resolution, 3.3V supply), 0.62µA average (14-bit resolution, 3.3V supply), one RH and temperature measurement per second
  • Excellent stability against aging

产品对比

应用

文档

类型 文档标题 日期
数据手册 PDF 1.06 MB
EOL 通告 PDF 748 KB
应用笔记 PDF 1.81 MB
应用笔记 PDF 131 KB
产品变更通告 PDF 368 KB
5 items

设计和开发

开发板与套件

模型

ECAD 模块

点击产品选项表中的产品,查找 SamacSys 中的原理图符号、PCB 足迹和 3D CAD 模型。点击产品选项表中的产品,查找 SamacSys 中的原理图符号、PCB 足迹和 3D CAD 模型。


Diagram of ECAD Models
