RH850/F1x, RH850/F1Kx 176-pin Piggyback Board of RH850 Evaluation Platform
The RH850/F1x 176-pin Piggyback Board supports all devices of the RH850/F1L and RH850/F1KM-S1 series in 176-pin package. It can be used standalone or in combination...
概览
描述
RH850/F1L 是瑞萨电子 RH850/F1x 系列单芯片微控制器中的产品线，专为汽车车身应用设计。 嵌入式闪存的范围 256KB 到 2MB，封装范围 48 引脚到 176 引脚的小型封装。
特性
- CPU：G3K 内核，最高 80MHz
- 电压：3V 到 5.5V
- 封装：48 到 176 引脚 LFQFP
- 内存：SRAM 最大 192KB，程序闪存最大 2MB
- 定时器：8 路 32 位定时器、48 路 16 位定时器、2 路看门狗定期器、OS x 1 路定时器
- PWM：72 路 PWM 输出，3 相 PWM 输出功能
- 模拟功能：4 路 10 位 A/D 转换器、91 路 12 位 A/D 转换器
- 片上振荡器 (MHz)：8MHz，低速：240kHz
- 其他：PLL、RTC、上电复位、低电压检测
