概览

描述

The RZ/G2E Reference Board from Silicon Linux Corporation is compatible with 96 boards equipped with the Renesas RZ/G2E MPU. It consists of two boards, a main board, and a subboard, and most of the RZ/G2E mounted functions can be evaluated by connecting to the subboard.

Note: When ordering the RZ/G2E board, please also add "EK874" to the message field of the inquiry form and send it. EK874 is only for evaluation, not for mass production.

Buy at CoreStaff ONLINE

特性

  • Processor: RZ/G2E
  • Main Memory: 2GB DDR3L
  • QSPI NOR Flash: 64MByte
  • I2C EEPROM: 512Byte
  • External Storage: micro SD x1
  • Connectivity: USB 2.0 x 2ch, USB 3.0 x 1ch, GbE x1
  • HDMI out / LVDS out or MIPI DSI out
  • Wi-Fi + BT
  • PMIC Renesas
  • Dimension: 54 mm x 85 mm

应用

文档

类型 文档标题 日期
快速入门指南 PDF 372 KB
1 item

设计和开发

软件与工具

软件与工具

Software title
Software type
公司
RZ/G Verified Linux Package [5.10-CIP]
Linux Packages for MPUs of the RZ/G2 Group. Functions of this products have been verified and regular maintenance is also provided.
Software Package 瑞萨电子
RZ/G Verified Linux Package for 64-bit Kernel [4.19-CIP]
This Linux package for 64-bit processors contains ported and tested basic software necessary for the industrial segment, and its operation and performance have been verified based on a datasheet. It enables you to start using a stable Linux environment and basic software immediately, so you can concentrate on developing your application.
Software Package 瑞萨电子
RZ MPU HTML5 (Gecko) Package for Verified Linux Packages [5.10-CIP]
HTML5 (Gecko) package for RZ/G. This package is used in combination with the Linux package provided for the device.
Software Package 瑞萨电子
3 items

软件下载

类型 文档标题 日期
PCB 设计文件 登录后下载 ZIP 19.82 MB
1 item
