射频放大器和增益模块

瑞萨提供的射频放大器组合专为通用视频和接收器应用设计。我们的高性能单片式微波集成电路 (MMIC) 硅双极差分放大器可用作单端到差分转换器，是各种通用应用的理想选择，它包括 HDTV 放大器、卫星中频（IF）增益模块和地面机顶盒，以及卫星定位器和信号强度计。

ISL55033

400MHz Slew Rate Enhanced Rail-to-Rail Output Gain Block

Processing table

	FMIN (MHz)	FMAX (MHz)	Frequency Range (MHz)	IS (per amp) (mA)	VS (Min) (V)	VS (Max) (V)	ZIN (ohms)	ZOUT (ohms)	Nch/Pch	NF@1GHz (dBm)	NF@2GHz (dB)	OIP3@1GHz (dBm)	OIP3 @ 1GHz Differential (dBm)	S11@1GHz (-dB)	S11 @ 1GHz Differential (-dB)	S12@1GHz (-dB)	S12 @ 1GHz Differential (-dB)	S21@1GHz (-dB)	S21 @ 1GHz Differential (-dB)	S22@1GHz (-dB)	S22 @ 1GHz Differential (-dB)	Bandwidth (MHz)	Lead Count (#)	Pkg. Type
(2) 推荐产品 (0) 衍生产品	最大值最小值	最大值最小值	最大值 Supported range of frequencies. 最小值 Supported range of frequencies.	最大值最小值	最大值最小值	最大值最小值	最大值最小值	最大值最小值		最大值最小值	最大值最小值	最大值最小值	最大值最小值	最大值最小值	最大值最小值	最大值最小值	最大值最小值	最大值最小值	最大值最小值	最大值最小值	最大值最小值	最大值最小值	最大值最小值	SC70 TQFN
器件号									Logical Operator															Logical Operator
ISL55014 PDF MMIC Silicon Bipolar Broadband Amplifier	500	3000	500 - 3000	63	3 V	5.5 V	50	50			4.3	30.3		20.8		22.2		17.2		12.8		2750	6	SC70
ISL55033 PDF 400MHz Slew Rate Enhanced Rail-to-Rail Output Gain Block				7.1	3 V	5.5 V																400	12	TQFN
