Renesas' high-speed, low-power, digital-to-analog data converters (DACs) are ideal for communication systems, medical/test instrumentation and equipment, and video applications.
Digital-to-Analog Converters (DAC)
跳转至页面部分：
产品选型表
Processing table
器件号 |
Resolution (bits) |
Conversion Rate (Max) (kSPS) |
Output I/V |
Supply Voltage Vs Range |
Integral NonLinearity LSB |
Differential NonLinearity LSB |
SFDR (Typical) to Nyquist |
Power (text) |
VREF |
Icc (Typical) (mA) |
Io (mA) |
Output Voltage (V) |
Application |
Remarks |
VS (Min) (V) |
VS (Max) (V) |
Qualification Level |
Lead Count (#) |
Pkg. Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 12-bit, +3.3V, 260MSPS, High Speed D/A Converter | 12 | 260000 | I | 3.3 | 1.25 | 1 | 73dBc 10MHz@130Msps | 157mW at 260Msps | Int/Ext | 3.3 V | 3.3 V | Standard | 28 | TSSOP | |||||
| 12-Bit, +3.3V, 210/130MSPS, CommLink High Speed D/A Converter | 12 | 130000 | I | 2.7 to 3.6 | 1.25 | 1 | 73dBc 10MHz@130Msps | 110mW at 200Msps | Int/Ext | 2.7 V | 3.6 V | Standard | 28 | TSSOP | |||||
| 14-Bit, +3.3V, 210/130MSPS, CommLink High-Speed D/A Converter | 14 | 210000, 130000 | I | 2.7 to 3.6 | 5 | 3 | 75dBc 10MHz@130Msps | 110mW at 200Msps | Int/Ext | 2.7 V | 3.6 V | Standard | 28 | TSSOP | |||||
| 8-bit 2ch D/A Converter with Buffer Amplifiers for I²C BUS (Corresponds to Fast mode) | 8 | V | 3 to 5 | 0.5 | 2 | D/A Converter | 2.7 to 5.5V Builtin Power On Reset | 8 | HWSON | ||||||||||
| 8-bit 2ch D/A Converter with Buffer | 8 | V | 3 to 5 | 0.7 | 2 | D/A Converter | 2.7 to 5.5V Builtin Power On Reset | 8 | HWSON | ||||||||||
| 8-bit 2ch D/A Converter with Buffer | 8 | V | 3 to 5 | 0.7 | 2 | D/A Converter | 2.7 to 5.5V Builtin Power On Reset | 8 | TSSOP | ||||||||||
| 8-bit 4ch D/A Converter with Buffer Amplifiers | 8 | V | 3 to 5 | 0.3 | 2 | D/A Converter | 2.7 to 5.5V Builtin Power On Reset | 16 | HWQFN | ||||||||||
| 8-bit 4ch D/A Converter with Buffer Amplifiers | 8 | V | 3 to 5 | 0.3 | 2 | D/A Converter | 2.7 to 5.5V Builtin Power On Reset | 16 | TSSOP | ||||||||||
| 8-bit 6ch D/A Converter with Buffer Amplifiers | 8 | V | 3 to 5 | 0.35 | 2 | D/A Converter | 2.7 to 5.5V Builtin Power On Reset | 16 | TSSOP | ||||||||||
| 8-bit 8ch D/A Converter with Buffer Amplifiers | 8 | V | 3 to 5 | 0.4 | 2 | D/A Converter | 2.7 to 5.5V Builtin Power On Reset | 16 | TSSOP | ||||||||||
| 8-bit 8ch D/A Converter with Buffer Amplifiers | 8 | V | 3 to 5 | 0.4 | 2 | D/A Converter | 2.7 to 5.5V Builtin Power On Reset | 16 | SOP | ||||||||||
| 8-bit 12ch D/A Converter with Buffer Amplifiers | 8 | V | 3 to 5 | 0.6 | 2 | D/A Converter | 2.7 to 5.5V Builtin Power On Reset | 20 | TSSOP | ||||||||||
| 8-bit 12ch D/A Converter with Buffer Amplifiers | 8 | V | 3 to 5 | 0.6 | 2 | D/A Converter | 2.7 to 5.5V Builtin Power On Reset | 20 | SOP | ||||||||||
| 8-bit 8ch Multiplying D/A Converter with Buffer Amplifiers | 8 | V | 3 to 5 | 1.5 | 2 | D/A Converter | 2.7 to 5.5V | 24 | HWQFN |
