特性
- Frequency: 71 – 86 GHz
- Input power range: -2 to + 23.5 dBm
- Insertion loss: 0.5dB, typical
- Return loss: >13dB
- RoHS compliant
- Die size: 0.87mm x 1.87mm
EXE8602 - Block Diagram
描述
The EXE8602 is a high-performance GaAs power detector with linear voltage output over an input operating power range from -2 to +23.5dBm, low insertion loss of 0.5dB typical, broadband performance from 71 to 86 GHz, return loss better than 13dB and excellent repeatability. This device can be used for a wide range of applications, from defense electronics to commercial communication systems, and is ideally used for E-band applications.
