概览

简介

RL78/I1C 微型计算机集成了智能电表计量所需的功能。 包括 24 位 ΔΣ A/D 转换器、32 位乘法累加器、独立电源实时时钟、支持多达 8 个 com 的分段 LCD 驱动程序以及支持 DLMS 标准的 AES 硬件引擎。 在单相两线表、单相三线表和三相三线表上使用 24 位 ΔΣ A/D 转换器(最大 4 通道)进行电流和电压检测,以实现高精度的功率计量。 100 引脚 QFP 产品还可支持三相四线电表,电流检测采用 ΔΣ A/D 转换器,电压检测采用逐次逼近 A/D 转换器。 此外,配备 512KB 闪存的产品还可以将代码闪存区作为两个分区(即 256KB x 2 个库)独立使用。 通过双库模式下的库编程功能和库交换功能,系统可以在整个新固件下载甚至是库交换期间不停止计量操作的情况下更新固件。

特性

  • CPU:RL78 核心,最高 32MHz
  • 电压:1.7V 至 5.5V
  • 封装:64 至 100 引脚 QFP
  • 存储器:SRAM 最大 32KB,程序闪存最大 512KB

产品对比

应用

应用

  • 计量

文档

设计和开发

软件与工具

软件与工具
