RX140 电容式触摸评估系统
RX140 电容式触摸评估系统使用户能够轻松评估瑞萨电子提供的触摸解决方案。 您可以使用套件中的电路板和软件即刻开始评估，开箱即用。
产品配置
- RX140 CPU 板
- 触摸应用板
- 内置电容式触摸的自电容式评估板基础知识：开关、滑块和滚轮
技术支持
可下载以下项目。
- e2 工作室集成开发环境
- 电容式触摸的 QE
- 快速入门指南
- 说明手册
- 电路图、模式图
概览
描述
Renesas' Metal Touch Solution applies capacitive touch technology using a Capacitive Touch Sensor Unit (CTSU) and a corresponding metal material overlay panel.
It is possible to assign multiple functions to a single button by determining the pressure applied from the amount of panel deflection as an added value.
特性
- Measure the change in capacitance caused by the deflection when pressing the button with a finger.
- Simultaneous detection of multiple button touches.
- Detection of three levels of touch intensity.
- User can adjust sensitivity and monitor changes in measured capacitance as a graph in real time by connecting with "QE for Capacitive Touch".
- Display the touched button number and provide feedback via a buzzer.
应用
- Home appliances
- AV equipment
- Industrial equipment
设计和开发
软件与工具
软件与工具
| Software title
|
Software type
|
公司
|
|---|---|---|
| QE for Capacitive Touch: Development Assistance Tool for Capacitive Touch Sensors In developing embedded system using the capacitive touch sensor of MCUs, you can easily setup initial configurations of the touch interface as well as process the tuning of sensors, and reduce development time. [Plugin for Renesas IDE "e2 studio"] [Standalone Version] [Support MCU/MPU:RA, RL78, RX, Renesas Synergy™]
|
Solution Toolkit | 瑞萨电子 |
1 item
|
||
样例程序
相关评估板和套件
视频和培训
介绍金属触摸解决方案
我们介绍了一种通过在金属面板上设计触摸按键的触摸解决方案。该解决方案不仅提升了产品的外观，还能够检测按钮按压的力度，从而实现传统电容触摸方案无法实现的触控效果。
欲了解更多信息，请访问金属触摸解决方案页面。
