特性
- Single supply: 1.8V to 5.5V
- Serial Peripheral Interface compatible (SPI bus) SPI mode 0 (0,0), 3 (1,1)
- Clock frequency: 5MHz (2.5V to 5.5V), 3MHz (1.8V to 5.5V)
- Power dissipation: Standby: 2.0μA (max) Active (Read): 2.0mA (max) Active (Write): 2.5mA (max)
- Automatic page write: 16-byte/page
- Write cycle time: 5ms
- Endurance: 1,000k or more Cycles at 25°C
- Data retention: 100 or more Years at 25°C
- Small-sized packages: SOP 8-pin, TSSOP 8-pin
- Shipping tape and reel TSSOP 8-pin: 3,000 IC/reel SOP 8-pin: 2,500 IC/reel
- Temperature range: −40°C to +85°C
- Lead-free product. (#U0, #S0)
- Halogen-free products. (#U0)
描述
The R1EX25002A is a Serial Peripheral Interface (SPI) compatible EEPROM (Electrically Erasable and Programmable ROM). It realizes high-speed, low-power consumption, and a high level of reliability by employing advanced MONOS memory technology and the CMOS process, and low-voltage circuitry technology. It also has a 16-byte page programming function to make its write operation faster.
产品参数
| 属性 | 值 |
|---|---|
| Interface | SPI bus |
| Memory Capacity (kbit) | 2 |
| Clock frequency (kHz) | 5000 |
| Supply Voltage (V) | - |
应用方框图
|
IO-Link 主机
IO-Link 网关套件将 8 个传感器/执行器与以太网连接，由 Arm Cortex-R52 MPU 控制。
|
