封装信息
| CAD 模型: | View CAD Model |
| Pkg. Type: | LGA |
| Pkg. Code: | LLC28 |
| Lead Count (#): | 88 |
| Pkg. Dimensions (mm): | 12.0 x 12.0 x 3.1 |
| Pitch (mm): | 1.5 |
环境和出口类别
| Moisture Sensitivity Level (MSL) | 3 |
| Pb (Lead) Free | Yes |
| RoHS (RYZ012A100FZ00#BD0) | 英语日文 |
| ECCN (US) | |
| HTS (US) |
产品属性
| Lead Count (#) | 88 |
| Carrier Type | Tray |
| Moisture Sensitivity Level (MSL) | 3 |
| Built-in Antenna | Available |
| Description | Module with internal antenna |
| Qty. per Reel (#) | 0 |
| Qty. per Carrier (#) | 168 |
| Pb (Lead) Free | Yes |
| Pb Free Category | e3 Sn |
| Temp. Range (°C) | -40 to 85°C |
| Country of Assembly | THAILAND |
| 2Mbps | Supported |
| AoA | Not Supported |
| AoD | Not Supported |
| Application | Asset tracking, Beacons, Connected health, Smart appliances, Industrial, Data pipes |
| Bluetooth® Mesh | Not Supported |
| CPU | Original 32-bit |
| Execute from FLASH | No |
| Extended Advertising | Not Supported |
| External Antenna | Available |
| External Rails and Load Capacity | None |
| Flash Memory (KB) | 512 |
| Flexible System Clock | No |
| GATT Caching | Not Supported |
| GPIOs (#) | 15 |
| Hardware Crypto Engine | No |
| I2C (#) | 0 |
| Integrated Battery Charger | No |
| Integrated DCDC | No |
| LE Coded PHY (Long Range) | Not Supported |
| LE Data Length Extensions | Supported |
| Lead Compliant | No |
| Length (mm) | 12 |
| MCU/MPU | Original 32-bit MCU |
| MOQ | 168 |
| Memory Size (OTP) (KB) | 64 |
| Output Power Range (dBm) | 10 - 10 |
| Periodic Advertising | Not Supported |
| Pitch (mm) | 1.5 |
| Pkg. Dimensions (mm) | 12.0 x 12.0 x 3.1 |
| Pkg. Type | LGA |
| Price (USD) | $7.39887 |
| Proprietary 2G4 protocol | No |
| QSPI Interface (#) | 0 |
| RAM (KB) | 64 |
| ROM (KB) | 64 |
| Rx current (mA) | 5.3 |
| SPI (#) | 0 |
| SPI (ch) | 1 |
| Sensitivity (dBm) (dBm) | -96 |
| Supply Voltage Vcc Range | 1.8-3.6 |
| Tape & Reel | No |
| Thickness (mm) | 3.1 |
| Tx Current (mA) | 4.8 |
| UART (#) | 2 |
| UART (ch) (#) | 1 |
| USB Ports (#) | 0 |
| Width (mm) | 12 |
| Wireless Standard | BLE 5.0 Core specification |
| With Host MCU | Available |
| Without Host MCU | Not Available |
| 已发布 | No |
有关 RYZ012x1 的资源
描述
RYZ012x1 是一款高度集成的无线通信模块，它可为蓝牙™ 5.0 低功耗 (LE) 提供预认证解决方案。 网络协议栈会在模块内部执行，因此无需进行外部协议栈操作。 该模块有两种配置 (RYZ012A1 和 RYZ012B1)，即装配有或未装配天线。 这不仅实现了灵活性，而且提供了更长无线距离需求的选项。 为了便于创建系统，该模块支持预定义的串行通信接口，可最大限度地减少软件工作量，并修整蓝牙 LE 学习曲线。 借助 RA MCU 系列的灵活配置软件包 (FSP) 和 QE for BLE 工具，客户可以专注于应用开发，而无需处理蓝牙 LE 的细节问题。
GATTBrowser － iOS/Android 应用程序
T可从 App Store/Google Play 下载智能手机应用程序 "GATTBrowser"。GATTBrowser 是一款检查 蓝牙LE 性能的应用。它可以扫描正在附近发送广告的 LE 设备，并利用互连的 LE 设备进行基于 GATT 的通信。通过它，您可以轻松查看示例应用程序的性能，并协助您拓展瑞萨电子的蓝牙LE微型计算机和模块设备。
GATTBrowser 下载：
