特性
- 120MHz Arm® Cortex®-M4 CPU
- Optimal for applications that require a high-performance Cortex-M4F core, that does not require on-chip graphic acceleration or Ethernet connectivity
- Available in a variety of packages
- Capacitive Touch Sensing Unit (CTSU)
- High precision data acquisition analog interfaces
- Enhanced security
S5D3 Block Diagram
描述
S5D3 为 S5 MCU 群组增加了产品层次, 适用于需要高性能 Cortex®-M4F 内核，但是不需要片上图形加速或以太网连接的应用，比同系列其他产品性价比更高。S5D3 采用高效的 40nm 工艺，提供了增强的安全性和广泛的连接性, 并得到 Synergy 软件包 (SSP) 的全面支持。
Synergy Software Package (SSP)
最佳化且紧密集成的适用软件套，具备可扩展最终产品复杂性并简化复杂系统级服务的商用RTOS。
产品参数
| 属性 | 值 |
|---|---|
| CPU Architecture | Arm |
| Main CPU | ARM Cortex-M4 |
| Program Memory (KB) | 512 |
| RAM (KB) | 256 |
| Carrier Type | Bulk (Tray), Full Carton (Tray) |
| Supply Voltage (V) | 2.7 - 3.6 |
| I/O Ports | 40, 76 |
| DMA (ch) | 8 |
| DRAM I/F | No |
| 3D GPU | No |
| Temp. Range (°C) | Ta = -40 to +85, Ta = -40 to +105 |
| Operating Freq (Max) (MHz) | 120 |
| Sub-clock (32.768 kHz) | Yes |
| On-chip Oscillator | Yes |
| Ethernet speed | No |
| Ethernet (ch) | 0 |
| EtherCat (ch) (#) | 0 |
| USB FS (host ch/device ch) | ( 1 / 1 ) |
| USB HS (host ch/device ch) | ( 0 / 0 ) |
| USB SS (host ch/device ch) | ( 0 / 0 ) |
| PCI Express (generation and ch) | No |
| SCI or UART (ch) | 7 |
| SPI (ch) | 2 |
| I2C (#) | 2 |
| CAN (ch) | 2 |
| CAN-FD (ch) | 0 |
| SDHI (ch) | 0, 2 |
| High Resolution Output Timer | Yes |
| PWM Output (pin#) | 22, 26 |
| 32-Bit Timer (ch) | 11, 13 |
| 16-Bit Timer (ch) (#) | 0 |
| 8-Bit Timer (ch) | 0 |
| Standby operable timer | Yes |
| Asynchronous General Purpose Timer / Interval Timer (ch) | 2 |
| 16-Bit A/D Converter (ch) | 0 |
| 14-Bit A/D Converter (ch) | 0 |
| 12-Bit A/D Converter (ch) | 10, 19 |
| 10-Bit A/D Converter (ch) | 0 |
| 24-Bit Sigma-Delta A/D Converter (ch) | 0 |
| 16-Bit D/A Converter (ch) | 0 |
| 12-Bit D/A Converter (ch) | 2 |
| 10-Bit D/A Converter (ch) (#) | 0 |
| 8-Bit D/A Converter (ch) | 0 |
| Capacitive Touch Sensing Unit (ch) | 7, 12 |
| Graphics LCD Controller | No |
| MIPI Interfaces (DSI) (ch) | 0 |
| MIPI Interfaces (CSI) (ch) | 0 |
| Image Codec | No |
| Segment LCD Controller | No |
| Security & Encryption | Unique ID, TRNG, AES(128/192/256), 3DES/ARC4, ECC/RSA/DSA, SHA1/SHA224/SHA256, GHASH |
应用
- 物联网智能边缘传感器
Renesas Boards & Kits
TB-S5D3目标板套件
体验 Synergy S5D3 MCU 群组的全部功能, 可使用所有引脚、标准化扩展端口和预安装的演示软件。
套件内容
- TB-S5D3 板
- USB Type A 转 USB Micro-B 电缆
系统要求
- 搭载以 2.0GHz 以上频率运行的 Intel® Core™ 系列处理器或同等处理器的 Microsoft® Windows® 7 或 10
- ≥ 8 GB 系统 RAM
- ≥ 2 GB 可用硬盘空间
- ≥ 2 个 USB 2.0 端口
- 互联网连接
