模拟产品

瑞萨电子的片上系统 (SoC) 音频处理器和 D 级放大器控制器可用于各种多通道音频系统配置，支持供电与线路输出。

产品选型表

    Processing table
    Input Channels
    PWM Output Channels
    Supported Audio Inputs
    Supported Audio Outputs
    Supported Decoders
    D2 Audio DSP Customization GUI
    Signal Flow
    Advanced Features
    Lead Count (#)
    Pkg. Type
    器件号
    D2-92634
    Intelligent Digital Amplifier and Sound Processor    		 8 12 2x S/PDIF, 4x I2S, 8x fault INT, ADC (opt), HDA 1x S/PDIF, 4x I2S, 12x PWM Dolby Digital 是的 Configurable D2Audio PWM Engine, Dolby Algorithm Support, Graceful Fault Recovery 128 LQFP
    D2-92643
    Intelligent Digital Amplifier and Sound Processor    		 8 12 2x S/PDIF, 4x I2S, 8x fault INT, ADC (opt), HDA 1x S/PDIF, 4x I2S, 12x PWM Dolby Digital 是的 Configurable
    D2 Audio DSP Sound Enhancement Algorithms, D2Audio PWM Engine and more...
    		 128 LQFP
    D2-92683
    Intelligent Digital Amplifier and Sound Processor    		 8 12 1x S/PDIF, 4x I2S, 8x fault INT 1x I2S, 1x S/PDIF, 12x PWM 是的 Configurable 147 MHz DSP, D2Audio PWM Engine, Graceful Fault Recovery 72 QFN
    D2-92684
    Intelligent Digital Amplifier and Sound Processor    		 8 12 1x S/PDIF, 4x I2S, 8x fault INT 1x I2S, 1x S/PDIF, 12x PWM Dolby Digital 是的 Configurable
    147 MHz DSP, D2Audio PWM Engine, Dolby Algorithm Support and more...
    		 72 QFN
