概览

描述

The 70914 is a high-speed 4K x 9 bit synchronous Dual-Port RAM that has been optimized for applications having unidirectional data flow or bi-directional data flow in bursts. The 70914 utilizes a 9-bit wide data path to allow for parity which is useful in data communication applications where it is necessary to use a parity bit for transmission/ reception error checking. An automatic power down feature, controlled by CE, permits the on-chip circuitry of each port to enter a very low standby power mode.

特性

  • Dual-Port RAM cells allows full simultaneous access from both ports
  • Synchronous operation
  • TTL-compatible, single 5V (+ 10%) power supply
  • Clock Enable feature
  • Guaranteed data output hold times
  • Available in 68-pin PLCC and 80-pin TQFP packages
  • Industrial temperature range (-40C to +85C) is available

产品对比

应用

文档

设计和开发

模型

ECAD 模块

点击产品选项表中的 CAD 模型链接,查找 SamacSys 中的原理图符号、PCB 焊盘布局和 3D CAD 模型。如果符号和模型不可用,可直接在 SamacSys 请求该符号或模型。

Diagram of ECAD Models

模型

类型 文档标题 日期
模型 - SPICE 登录后下载 Z 11 KB
模型 - IBIS ZIP 9 KB
2 items
