概览

描述

The 83210 is a low skew, 1-to-10 HSTL Fanout Buffer. The class II HSTL outputs are balanced push-pull in design, capable of delivering 16mA into a 10pF load. This class allows both source series termination and symmetrically double parallel termination.

特性

  • Ten single-ended HSTL outputs
  • One single-ended HSTL clock input
  • Maximum input frequency: 150MHz
  • Output skew: 110ps (maximum)
  • Part-to-part skew: 2ns (maximum)
  • 1.5V power supply
  • 0°C to 85°C ambient operating temperature
  • Available in lead-free (RoHS 6) package

产品对比

应用

文档

设计和开发

模型

ECAD 模块

点击产品选项表中的 CAD 模型链接,查找 SamacSys 中的原理图符号、PCB 焊盘布局和 3D CAD 模型。如果符号和模型不可用,可直接在 SamacSys 请求该符号或模型。

Diagram of ECAD Models

模型

模型 - IBIS ZIP 42 KB
1 项目
