特性
- Data rate up to 64Gbps per channel for 400G/600G DP-mQAM applications
- > 40GHz Bandwidth
- > 10dB dynamic range of gain control
- 2.4W (typical) at linear 4.0Vppd
- AC-coupled 100Ω differential input/open-collector configuration at the output
- Ultra-low inter-channel cross-talk
- Peaking adjustment functionality
- Analog control for gain and output voltage setting, and analog monitor for peak detector and gain control monitor
- Optical Internetworking Forum (OIF)-compliant SPI digital interface integration
描述
The GX76474 is a low-power, high-performance, quad-channel linear driver chip. It is designed for 400G/600G optical integrated transmitter small form factor (SFF) modules for metro and long-haul applications.
The GX76474 integrates the quad lanes of the driver with SPI circuitry for DC controls on a single die. Each channel of the driver has a 100Ω differential AC-coupled input and 60Ω differential interface with an open-collector type output stage, and linear output voltage of 4.0Vppd suitable for silicon photonics modulator and multi-level modulations.
产品参数
| 属性 | 值 |
|---|---|
| Function | Linear Driver |
| Data Rate Max (Gbps) | 64 |
| Channels (#) | 4 |
| Output Type | Differential |
| Output Voltage (V) | 4 |
封装选项
| Pkg. Type |
|---|
| WAFER |
应用方框图
|
400ZR 光模块
使用小型 400ZR 模块优化 DCI 链路上的 400Gb 以太网传输，以实现高性能和低功耗。
|
