GreenPAK SLG46170 Development Kit with Socket Adapter
The SLG46170V-SKT includes the SLG4SA14-20x22 socket adapter and 50 SLG46170V samples.
概览
描述
The SLG46170 provides a small, low-power component for commonly used mixed-signal functions. The user creates their circuit design by programming the one-time programmable (OTP) non-volatile memory (NVM) to configure the interconnect logic, the I/O pins, and the macrocells of the SLG46170. This highly versatile device allows for a wide variety of mixed-signal functions to be designed within a very small, low-power single integrated circuit.
特性
- Logic and Mixed-Signal Circuits
- Highly Versatile Macrocells
- Read Back Protection (Read Lock)
- 1.8V (±5%) to 5V (±10%) Supply
- Operating Temperature Range: -40 °C to 85 °C
- RoHS-Compliant/Halogen-Free
- Macrocells Overview
- Fifteen Combinatorial Look-Up Tables (LUTs)
- Five 2-bit LUTs
- Nine 3-bit LUTs
- One 4-bit LUT
- Two Combination Function Macrocell
- One Selectable DFF/Latch or 2-bit LUT
- One Selectable Pipe Delay or 3-bit LUT
- Pipe Delay - 16 Stage/3 Output
- Eight Counter/Delay Generators (CNT/DLY)
- Two 14-bit Delay/Counter
- One 14-bit Delay/Counter with External Clock/Reset
- Three 8-bit Delay/Counters
- Two 8-bit Delay/Counters with External Clock/Reset
- Six D Flip-Flop/Latches (DFF)
- Pipe Delay - 16 Stage/3 Output (Part of Combination Function Macrocell)
- Programmable Delay
- Additional Logic Functions - 2 Deglitch Filters
- RC Oscillator (RC OSC)
- Fifteen Combinatorial Look-Up Tables (LUTs)
产品对比
应用
- Personal Computers and Servers
- PC Peripherals
- Consumer Electronics
- Data Communications Equipment
- Handheld and Portable Electronics
