对于刚接触该技术的用户来说,为系统添加 Bluetooth® Low Energy (LE) 功能可能具有一定挑战性。 要创建具有必备无线性能并获得相关审批的最终产品,从组件选择到射频布局和监管认证都任务量巨大。
使用经过认证的模块对这项工作大有帮助。 瑞萨电子的所有蓝牙 LE 模块均通过合规性认证、蓝牙认证和外部电路认证,因此客户无需自行将其集成到产品中。 参数搜索表中内置天线和外置天线列中标注为 “可用” (available) 的产品为模块化产品。 此外,瑞萨电子还为最终产品提供蓝牙认证指南。
Application |
Wireless Standard |
Proprietary 2G4 protocol |
CPU |
Flash Memory (KB) |
ROM (KB) |
Memory Size (OTP) (KB) |
RAM (KB) |
GPIOs (#) |
Supply Voltage Vcc Range |
Integrated DCDC |
Integrated Battery Charger |
External Rails and Load Capacity |
Tx Current (mA) |
Rx current (mA) |
Output Power Range (dBm) |
Sensitivity (dBm) (dBm) |
Clock Rate (MHz) |
Flexible System Clock |
Execute from FLASH |
Hardware Crypto Engine |
QSPI Interface (#) |
SPI (#) |
I2C (#) |
UART (#) |
ADC |
USB Ports (#) |
LE Data Length Extensions |
2Mbps |
LE Coded PHY (Long Range) |
Advertising Extensions |
Periodic Advertising |
AoA |
AoD |
GATT Caching |
Bluetooth® Mesh |
Pkg. Type |
|
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
器件号 | |||||||||||||||||||||||||||||||||||||
超高集成度的蓝牙™ 5.2单芯片解决方案 | Rechargeables, HMI, Wearables, Smart Home, E-bike, Consoles | BLE 5.2 Core specification + optional features | Yes | M33F | 0 | 32 | 4 | 1536 | 79 | 2.9-4.75 | Yes, Low-IQ SIMO Buck & 4.5-5V Boost | Yes, 720mA JEITA compliant charger | 2 x 1.8V @ 100mA each | 3 | 1.85 | 6 | -97 | 160 | 是的 | 是的 | 是的 | 3 | 3 | 4 | 3 | 11 ENOB, 16Ksps with PGA | 1 | Supported | Supported | No | CABGA | ||||||
超高集成度的蓝牙™ 5.2单芯片解决方案 | Rechargeables, HMI, Wearables, Smart Home, E-bike, Consoles | BLE 5.2 Core specification + optional features | Yes | M33F | 0 | 32 | 4 | 1536 | 79 | 2.9-4.75 | Yes, Low-IQ SIMO Buck & 4.5-5V Boost | Yes, 720mA JEITA compliant charger | 2 x 1.8V @ 100mA each | 3 | 1.85 | 6 | -97 | 160 | 是的 | 是的 | 是的 | 3 | 3 | 4 | 3 | 11 ENOB, 16Ksps with PGA | 1 | Supported | Supported | No | CABGA | ||||||
超高集成度的蓝牙™ 5.2单芯片解决方案 | Rechargeables, HMI, Wearables, Smart Home, E-bike, Consoles | BLE 5.2 Core specification + optional features | Yes | M33F | 0 | 32 | 4 | 1536 | 79 | 2.9-4.75 | Yes, Low-IQ SIMO Buck & 4.5-5V Boost | Yes, 720mA JEITA compliant charger | 2 x 1.8V @ 100mA each | 3 | 1.85 | 6 | -97 | 160 | 是的 | 是的 | 是的 | 3 | 3 | 4 | 3 | 11 ENOB, 16Ksps with PGA | 1 | Supported | Supported | No | CABGA | ||||||
超高集成度的蓝牙™ 5.2单芯片解决方案 | Rechargeables, HMI, Wearables, Smart Home, E-bike, Consoles | BLE 5.2 Core specification + optional features | Yes | M33F | 0 | 32 | 4 | 1536 | 79 | 2.9-4.75 | Yes, Low-IQ SIMO Buck & 4.5-5V Boost | Yes, 720mA JEITA compliant charger | 2 x 1.8V @ 100mA each | 3 | 1.85 | 6 | -97 | 160 | 是的 | 是的 | 是的 | 3 | 3 | 4 | 3 | 11 ENOB, 16Ksps with PGA | 1 | Supported | Supported | No | CABGA | ||||||
SmartBond™ Low Power Bluetooth 5.1 System-on-Chip | Low cost BLE connectivity front-end and data pipe | BLE 5.1 Core specification | No | M0+ | 0 | 144 | 32 | 48 | 12 | 1.8-3.3 | N/A | No | 3.5 | 2.2 | 2.5 | -94 | 16 | 是的 | 否 | 是的 | 1 | 1 | 2 | 4ch 10b | 0 | Supported | FCGQFN | ||||||||||
SmartBond™ Ultra-Low Power Bluetooth® 5.1 System-on-Chip | Asset tracking, Beacons, Connected health, Disposables, RCU | BLE 5.1 Core specification | No | M0+ | 0 | 144 | 32 | 48 | 12 | 1.1-3.6 | Integrated Buck/Boost DC-DC converter | No | 3.5 | 2.2 | 2.5 | -94 | 16 | 是的 | 否 | 是的 | 1 | 1 | 2 | 4ch 10b | 0 | Supported | FCGQFN, WLCSP | ||||||||||
SmartBond TINY™ Bluetooth® Low Energy Module | Asset tracking, Beacons, Connected health, Disposables, RCU | BLE 5.1 Core specification | No | M0+ | 0 | 144 | 32 | 48 | 12 | 1.1-3.6 | Integrated Buck DC-DC converter | No | 3.5 | 2.2 | 2.2 | -94 | 16 | 是的 | 否 | 是的 | 1 | 1 | 2 | 4ch 10b | 0 | Supported | MODULE | ||||||||||
SmartBond™ Bluetooth 5.0 SoC with Audio Interface | Beacons, Proximity Tags, Human Interface Devices, RCU | BLE 5.0 Core specification | No | M0 | 0 | 128 | 64 | 96 | 14, 25 | 0.9-3.5 | Integrated Buck/Boost DC-DC converter | No | 4.8, 4.9 | 5.1, 5.3 | -93 | 16 | 否 | 否 | 是的 | 1 | 1 | 2 | 4ch 10b | 0 | Supported | QFN40, WLCSP34 | |||||||||||
SmartBond™ Bluetooth 5.0 SoC with Audio Interface and 2Mbit Flash | Beacons, Proximity Tags, Human Interface Devices, RCU | BLE 5.0 Core specification | No | M0 | 256 | 128 | 64 | 96 | 24 | 1.8-3.5 | Integrated Buck DC-DC converter | No | 4.9 | 5.3 | -93 | 16 | 否 | 否 | 是的 | 1 | 1 | 2 | 4ch 10b | 0 | Supported | QFN40 | |||||||||||
SmartBond™ Bluetooth® Low Energy 5.0 SoC with Enhanced Security and Flash | Rechargeable devices, charging cases, USB-to-BLE dongles | BLE 5.0 Core specification | No | M0 | 1024 | 128 | 64 | 128 | 31 | 1.7-4.75 | SIMO Buck DC-DC converter | Yes, 400mA USB charger | 1.8V @ 75mA | 5.2 | 6 | -94 | 96 | 是的 | 是的 | 是的 | 2 | 2 | 2 | 8ch 10b | 1 | Supported | On request | AQFN60 | |||||||||
SmartBond™ Bluetooth® Low Energy 5.0 SoC with Enhanced Security | Rechargeable devices, Banking, Industrial, USB-to-BLE dongles | BLE 5.0 Core specification | No | M0 | 0 | 128 | 64 | 128 | 37 | 1.7-4.75 | SIMO Buck DC-DC converter | Yes, 400mA USB charger | 1.8V @ 75mA | 5.2 | 6 | -94 | 96 | 是的 | 是的 | 是的 | 1 | 2 | 2 | 2 | 8ch 10b | 1 | Supported | On request | AQFN60, WLCSP53 | ||||||||
Multi-Core Bluetooth® 5.2 SoC with System Power Management Unit | General purpose connectivity MCU | BLE 5.2 Core specification + optional features | Yes | M33F | 0 | 128 | 4 | 384 | 44 | 2.4-4.75 | SIMO Buck DC-DC converter | No | 1x 3V @ 110mA, 3x 1.8V @ 50mA each | 3 | 1.8 | -97 | 96 | 是的 | 是的 | 是的 | 1 | 2 | 2 | 3 | 8ch 10b, 8ch 14b | 1 | Supported | Supported | Supported | Supported | Supported | TX Supported | |||||
Multi-Core Bluetooth® 5.2 SoC with System Power Management Unit | Rechargeable devices, HMI | BLE 5.2 Core specification + optional features | Yes | M33F | 0 | 128 | 4 | 512 | 44 | 2.4-4.75 | SIMO Buck DC-DC converter | Yes, 560mA JEITA compliant charger | 3x 1.8V @ 50mA each | 3 | 1.8 | 6 | -97 | 96 | 是的 | 是的 | 是的 | 1 | 2 | 2 | 3 | 8ch 10b, 8ch 14b | 1 | Supported | Supported | Supported | Supported | Supported | TX Supported | VFBGA86 | |||
SmartBond 低功耗蓝牙™ 5.2 高集成度(包括 USB 充电器)模块 | Rechargeable devices, HMI | BLE 5.2 Core specification + optional features | Yes | M33F | 32000 | 128 | 4 | 512 | 40 | 2.4-4.75 | SIMO Buck DC-DC converter | Yes, 560mA JEITA compliant charger | 1x 3V @ 150mA, 3x 1.8V @ 50mA each | 3 | 1.8 | 6 | -96 | 96 | 否 | 是的 | 是的 | 1 | 2 | 2 | 3 | 4ch 10b, 4ch 14b | 1 | Supported | Supported | Not Supported | Supported | Supported | Supported | TX Supported | Not Supported | Not Supported | MODULE |
Multi-Core Bluetooth® 5.2 SoC with System Power Management Unit | Rechargeable devices, HMI, Wearables | BLE 5.2 Core specification + optional features | Yes | M33F | 0 | 128 | 4 | 512 | 55 | 2.4-4.75 | SIMO Buck DC-DC converter | Yes, 560mA JEITA compliant charger | 3x 1.8V @ 50mA each | 3 | 1.8 | 6 | -97 | 96 | 是的 | 是的 | 是的 | 2 | 2 | 2 | 3 | 8ch 10b, 8ch 14b | 1 | Supported | Supported | Supported | Supported | Supported | TX Supported | VFBGA | |||
Multi-Core Bluetooth® 5.2 SoC with System Power Management Unit | Rechargeable devices, HMI, Wearables, 'Analog' Smart Watches | BLE 5.2 Core specification + optional features | Yes | M33F | 0 | 128 | 4 | 512 | 55 | 2.4-4.75 | SIMO Buck DC-DC converter | Yes, 560mA JEITA compliant charger | 3x 1.8V @ 50mA each | 3 | 1.8 | 6 | -97 | 96 | 是的 | 是的 | 是的 | 2 | 2 | 2 | 3 | 8ch 10b, 8ch 14b | 1 | Supported | Supported | Supported | Supported | Supported | TX Supported | VFBGA | |||
带有 48 MHz Bluetooth® 5.0 的低功耗单芯片 32 位微控制器 | BLE 5.0 Core specification + optional features | ARM Cortex-M4 | 512 | 96 | 35 | 1.8-3.6 | 4.5 | 3.3 | 4 | -95 | 48 | 否 | 否 | 是的 | 0 | 2 | 2 | 6 | 14-bit x 8-ch | 1 | Supported | Supported | Supported | Not Supported | Not Supported | Not Supported | Supported | QFN | |||||||||
Bluetooth® Low Energy Microcontrollers for Smart Connectivity | BLE 5.0 Core specification | RL78 | 128, 192, 256 | 12, 16, 20 | 32 | 1.6-3.6 | 4.3 | 3.5 | -90 | 32 | 否 | 否 | 否 | 0 | 0 | 3 | 2 | 10-bit x 8-ch | 0 | Not Supported | Not Supported | Not Supported | Not Supported | Not Supported | Not Supported | Not Supported | HWQFN, MLZZ0042ZA-A | ||||||||||
32位单片机和模块产品,可在单个芯片上实现Bluetooth®5无线通信和系统控制,适用于IoT终端设备 | BLE 5.0 Core specification + optional features | RXv2 | 512, 384 | 64 | 44, 30 | 1.8-3.6 | 4.3 | 3 | 4 | -95 | 54 | 否 | 否 | 否, 是的 | 0 | 4, 5 | 4, 5 | 3, 4 | 12-bit x 8-ch, 12-bit x 14-ch | 1 | Supported | Supported | Supported | Not Supported | Not Supported | Not Supported | Supported | HVQFN, TFBGA, TFLGA | |||||||||
蓝牙低功耗 (LE) 模块 | BLE 5.0 Core specification | Original 32-bit | 1.8-3.6 | 4.8 | 5.3 | 10 | -96 | 否 | 否 | 否 | 0 | 0 | Supported | Supported | Not Supported | Not Supported | Not Supported | Not Supported | Not Supported | LGA |
