特性
- True dual-ported memory cells allow simultaneous access of the same memory location
- On-chip port arbitration logic
- Interrupt flags for port-to-port communication
- Fully asynchronous operation from either port
- Battery backup operation, 2V data retention (L only)
- TTL-compatible, single 3.3V ±0.3V power supply
- Available in a 64-pin STQFP package
- Industrial temperature range (–40 °C to +85 °C) is available
描述
The 71V30 high-speed 1K x 8 dual-port static RAM is designed to be used as a stand-alone 8-bit dual-port SRAM. It has two independent ports with separate control, address, and I/O pins that permit independent, asynchronous access for reads or writes to any location in memory. An automatic power-down feature, controlled by CE, permits the on-chip circuitry of each port to enter a very low standby power mode.
产品参数
| 属性 | 值 |
|---|---|
| Core Voltage (V) | 3.3 |
| Bus Width (bits) | 8 |
| Density (Kb) | 8 |
| Pkg. Code | PPG64 |
| Interface | Async |
| I/O Type | 3.3 V LVTTL |
| Access Time (ns) | 25, 35, 55 |
| Temp. Range (°C) | -40 to 85°C, 0 to 70°C |
| Architecture | Dual-Port |
| Organization | 1K x 8 |
| Function | Busy, Interrupt, Master |
封装选项
| Pkg. Type | Pkg. Dimensions (mm) | Lead Count (#) | Pitch (mm) |
|---|---|---|---|
| TQFP | 10.0 x 10.0 x 1.4 | 64 | 0.5 |
