SLG47105

有效
产品长期供货

HVPAK Programmable Mixed-Signal IC, VDD Range: 2.3-5.5V, 12 GPIOs, 2 ACMPs, I2C, Quad Half-Bridge Driver (13.2V, 2A)

立即订购

特性

  • Up to 13.2V High Voltage and up to 2A High Current Drive GPOs
  • Full H-Bridge and Independent Half-Bridge Control
  • Flexible 8-bit PWMs Macrocells
  • Constant Current Regulation
  • Constant Voltage Regulation
  • Two Wide Range Power Supply Inputs
    • 2.5V (±8%) to 5.0V (±10%) VDD
    • 3.3V (±10%) to 12.0V (±10%) VDD2
  • Built-in Protections:
    • Undervoltage Lockout
    • Overcurrent Protection
    • Thermal Shutdown
  • I2C control
  • Operating Temperature Range: -40°C to 85°C
  • One-Time Programmable Non-Volatile Memory
  • Low current consumption (nA level)
  • RoHS-Compliant/Halogen-Free
  • Macrocells Overview
    • Four High Voltage, Current Drive GPOs with low RDS_ON
    • Two 8-bit PWM Macrocells with Built-in 16-byte Register File
    • Two Oscillators
      • 2.048kHz oscillator
      • 25MHz oscillator
    • Two High-Speed General-Purpose Rail-to-Rail Analog Comparators with Integrated Voltage Reference
    • Differential Amplifier with Integrator and Analog Comparator
    • Two Current Sense Comparators with Integrated Voltage Reference
    • Twelve Combination Function Macrocells
      • Three Selectable DFF/Latch or 2-bit LUTs
      • One Selectable Programmable Pattern Generator or 2-bit LUT
      • Six Selectable DFF/Latch or 3-bit LUTs
      • One Selectable Pipe Delay or Ripple Counter or 3-bit LUT
      • One Selectable DFF/Latch or 4-bit LUT
    • I2C Serial Communication Macrocell
    • Temperature Sensor
    • Filter with Edge Detector
    • Programmable Delay with Edge Detector
    • Power-On Reset (POR)
查找HVPAK的其他产品
SLG47105 Block Diagram
SLG47105 / SLG47115 HVPAK High Voltage Programmable Mixed-Signal IC Overview
SLG47105 Block Diagram
SLG47105 / SLG47115 HVPAK High Voltage Programmable Mixed-Signal IC Overview

描述

The SLG47105 combines mixed-signal logic and high-voltage H-bridge functionality in a tiny 2mm x 3mm QFN package. A one-time programmable (OTP) non-volatile memory (NVM) stores user-defined solutions in the form of interconnections of internal logic, I/O pins, and macrocells. Integrated dual H-Bridge/quad Half-Bridge functionality allows driving different loads up to 2A per output with up to 13.2V voltage. The SLG47105 advanced PWM macrocells provide the ability to drive multiple motors with different PWM frequencies and duty cycles. Low idle current consumption in combination with a compact size further extends the field of possible applications. This highly versatile device allows for a wide variety of mixed-signal functions to be designed alongside high-voltage capabilities within a tiny and thermally efficient IC.

此为出厂可配置设备。
试用自定义部件配置工具。

产品参数

属性 值
Nominal VDD 2.3 - 5.5
VDD2 (V) 3 - 13.2
GPIOs (#) 12
Special Features 2x CCMP, 2x H-/4x Half-Bridge, 2x PWM, Int&Diff Amp
ACMP Channels (#) 2
CNT/DLY (Max) (#) 5
LUTs (Max) (#) 17
DFF (Max) (#) 15
Pipe Delay 16-stage
# of Programable Delays (#) 1
Oscillator Type LF OSC, Ring OSC
Temperature Sensor (ch) (#) 1
Interface I2C
Memory Type OTP
Temp. Range (°C) -40 to +85°C

封装选项

Pkg. Type Pkg. Dimensions (mm) Lead Count (#) Pitch (mm)
TQFN 2.0 x 3.0 20 0.4

产品对比

SLG47105 SLG47115
VDD2 3.0 - 13.2 4.5 - 26.4
Peak Output Current IPK (A) 2 3
GPIOs (#) 12 10
Special Features 2x CCMP, 2x H-/4x Half-Bridge, 2x PWM, Int&Diff Amp 1x H-/2x Half-Bridge, 2x PWM, CCMP, Int&Diff Amp

应用方框图

Battery-powered aroma diffuser featuring ultra-low power Wi-Fi 6, battery charger and compact mixed-signal IC.
家用香薰机
具有互联性和灵活供电选项的家用香薰机。
Automatic pet door and tracking system block diagram featuring Wi-Fi and Bluetooth Low Energy connectivity, versatile HMI, mixed-signal ICs, and NFC.
自动宠物门与追踪系统
带标签系统的智能宠物门，可通过近距离检测技术实现宠物自动进出与走失追踪功能。
Pet camera robot system interactive block diagram features a dual-core Arm Cortex-M88 MCU with immutable storage, RSIP cryptographic engine, TrustZone, and tamper protection.
宠物摄像机器人
具有实时视频、音频和无线控制功能的移动宠物摄像机器人。
Interactive block diagram of the 3-phase AC motor with a soft start features an MCU, HVPAK and optional bus interfaces.
3 相交流电机软启动
采用相位角控制技术的软启动器，可实现三相交流电机的平稳加速启动，并通过继电器旁路简化布线。
Interactive block diagram of the heatstroke prevention watch features and ultra-low power MCU, single-chip NFC charging, and low-energy flash memory.
防中暑手表
一款低功耗可穿戴设备，能够检测中暑风险，提醒用户尽早采取行动。
Dual-needle gauge interactive block diagram displays multiple real-time values for fast, intuitive analog monitoring.
双指针仪表
双指针仪表可以实时显示两个数值，实现快速直观的模拟监测。
Smart Fish Tank Block Diagram
智能鱼缸
智能鱼缸可通过基于 Wi-Fi 的移动应用程序控制自动换水功能。
Smart Cradle Block Diagram
智能摇篮
具有哭声检测、实时警报、自动摆动功能和蓝牙移动应用程序支持的智能底座。
Electric Toothbrush with UV Sanitation Block Diagram
紫外线杀菌电动牙刷
配备紫外线杀菌和 NFC 牙刷识别功能的电动牙刷。
The smart lock platform designed to support Aliro features NFC, Bluetooth, Wi-Fi, optional UWB connectivity, and LTE connectivity, and can be powered by disposable primary cell batteries or a li-ion battery rechargeable via NFC wireless charging.
支持 Aliro 的中档智能锁——为即将推出的新标准而设计
智能锁平台专为支持 Aliro 设计，提供安全访问并优化功耗。
Thermometer with Wireless Sensor Block Diagram
智能烧烤温度计
智能烧烤温度计提供实时温度监测和无线连接功能，可更安全、更完美地烹制美食。
This Apple HomeKit-ready smart lock system features Bluetooth, NFC, and optional ultra-wideband (UWB) technology enabling secure and convenient door access.
支持 Apple HomeKit 的基础款智能锁
Apple HomeKit 智能锁可通过蓝牙、NFC、Wi-Fi 和 UWB 实现安全访问。
Bluetooth Low Energy Tags for Crowdsourced Location Tracking Block Diagram
众包位置跟踪低功耗蓝牙标签
超低功耗蓝牙 LE 资产定位追踪器标签，用于众包位置跟踪。
1.2kW High-Voltage Inverter with GaN-based Power Factor Correction (PFC) Block Diagram
1.2kW 高压 GaN 逆变器
采用了基于 GaN 的 PFC 的高效高压 GaN 逆变器，适用于工业电机驱动。
500W Onboard Battery Charger for 2-Wheeler EV Block Diagram
适用于两轮电动车的 500W 车载电池充电器
具有 GaN FET 和 MCU 的高效 AC/DC 电池充电器，用于进行 CAN 通信和保护电池健康。
