特性
- 5V ±5% Power supply
- SLG55021 Drain Voltage Range 1.0V to 20V
- Internal Gate Voltage Charge Pump
- Controlled Turn on Delay
- Controlled Load Discharge Rate
- Controlled Turn on Slew Rate
- Stable Slew Rate (±2% typ.) Over Temperature Range
- TDFN-8 Package
- Pb-free/Halogen-Free/RoHS compliant
描述
The SLG55021 is a high-voltage gate driver with an internal charge pump for a single N-Channel MOSFET with VGS < 20V. Soft switching 1.0V to 20V power rail.
产品参数
| 属性 | 值 |
|---|---|
| Supply Voltage Vcc Range | 5V |
| Input Voltage Range (V) | 1 - 20 |
| Number of Controlled Supplies (#) | 1 |
封装选项
| Pkg. Type | Pkg. Dimensions (mm) | Pitch (mm) |
|---|---|---|
| TDFN-8 | 2.5 x 2.5 | 0.4 |
应用
- Power Rail Switches
- Hot Plugging Applications
- Soft Switching
- Personal computers and Servers
- Data Communications Equipment
