概览
描述
The SLG59M1466V is designed for load switching applications. The part comes with one 40 mΩ 1.0 A‑rated MOSFET controlled by a single ON control pin. The MOSFET’s ramp rate is fixed at 3 V/ms. The product is packaged in an ultra‑small 1.0 mm x 1.0 mm package.
特性
- Optimized for smartphone, notebook/tablet PC applications
- 40 mΩ RDSON while supporting 1.0 A
- Power supply/input voltage range: 2.5 V ≤ VD ≤ 5.5 V
- Output voltage slew-rate control internally fixed
- Output discharge circuitry
- Sleep mode current (IDDOFF) in low µA range
产品对比
应用
设计和开发
软件与工具
开发板与套件
评估
SLG59M1466V Evaluation Board
The SLG59M1466V-EVB board evaluates the SLG59M1466V GreenFET, Single N-Channel, Load Switch.
模型
ECAD 模块
点击产品选项表中的 CAD 模型链接，查找 SamacSys 中的原理图符号、PCB 焊盘布局和 3D CAD 模型。如果符号和模型不可用，可直接在 SamacSys 请求该符号或模型。
产品选项
当前筛选条件
视频和培训
Introduction to Ultra Low RDSon Load Switches
Video List
