特性
- Wi-Fi 6 (802.11ax) R2
- Concurrent dual-band, dual transceiver
- 4T4R MIMO architecture
- 3Gbps aggregated PHY/data link speed
- Single PCIe 3.0 (dual-lane) interface
- Small 11mm x 11mm BGA package
- DL/UL MU-OFDMA support
- DL MU-MIMO support
- Beamforming support
- Target-Wait-Time
- Uplink scheduling
- QAM 1024 (MCS 10, 11) modulation
- 20, 40, 80, 160MHz support in 5GHz
- 20 and 40MHz support in 2.4GHz
- WEP CAC support to enable seamless channel change to DFS channels
- WEP 64/128, WPA, WPA2, WPA3, TKIP, AES, WAPI
- QoS-WMM, WMM-PS, WMM-ACM
- IEEE 802.11e, h, i, k, r, v, w, z support
描述
The CL8040 is a high-performing, highly integrated Wi-Fi 6 (802.11ax) R2 single PCIe chip that delivers the best Wi-Fi network performance for its size by combining two Wi-Fi 6 radios into a single 11mm x 11mm PCIe chip. The chip employs two concurrent dual-band Wi-Fi 6 radios with 4T4R architecture that can drive aggregated PHY/data link speeds up to 3Gbps. The two independent radios can function as an access point, client, or as repeater.
CL8040 integrates dual MAC, dual PHY, analog and RFIC in a single package, including the required CPUs and memories to run more of the wireless LAN functions on-chip, eliminating the need for costly external memories. Interface to the host is over a dual-lane PCIe 3.0 interface.
The CL8040 is designed to support standard-based features addressing security, quality of service, and international regulation, as well as above-standard integrated value-add functionalities based on Renesas’s embedded and edge software technologies
产品参数
| 属性 | 值 |
|---|---|
| Wireless Standard | Wi-Fi 6 (802.11ax) |
| Band | 2.4 GHz + 5 GHz |
| MIMO | 4T4R system |
应用方框图
|
自主移动机器人（AMR）
具备 AI 功能的 AMR 系统，集实时控制、可扩展电源和紧凑设计于一体。
|
|
标准机械臂系统
具有 AI 视觉和实时运动控制功能的机械臂系统。
|
|
高性能视觉 AI 系统
高端视觉 AI 系统具有实时目标检测功能与高效 AI 加速器。
|
|
客户端设备高速 5G 转 Wi-Fi 转换器
使用双频 4T4R Wi-Fi 6 将 5G 转换为 Wi-Fi，非常适合 5G 路由器和高效联网。
|
|
Android 系统互联车载仪表
采用 Android 系统的汽车驾驶舱，具有无线连接和实时显示功能。
|
|
无线电子游戏桌
灵活的 Wi-Fi 6 系统提供 3000Mbps、4x4 MIMO、双频支持以及无缝集成功能。
|
|
Wi-Fi 连接的零售秤
Wi-Fi 6 零售秤支持快速交易、连接稳定、设计紧凑、用电高效。
|
|
自动光学检测（AOI）
具有 DRP-AI 和 Wi-Fi 6 支持的强大 MPU，适用于高速、低延迟的 AOI 系统。
|
|
高吞吐率 Wi-Fi 6 路由器
使用由瑞萨电子提供支持的高级 Wi-Fi 6 路由器，体验丝滑、高速的连接。
|
|
支持 Wi-Fi 6 的工业网关
工业网关通过 Wi-Fi 6 实现网络与设备之间的桥接，促进数据交换与控制。
|
其他应用
- Home Gateways
- Multimedia Gateways
- Enterprise Access Points
- SMB Access Points
- Routers
- Extenders
- Mesh Nodes
- Bandwidth-Intense Connected IoT
- Smart TVs
- Industrial PLCs
