概述
描述
The Gear Shifter reference design circuit manages electronic gear selection using a microcontroller-based system (MCU) and inductive position sensing (IPS). It integrates power regulation, input decoding, and CAN communication for seamless vehicle interaction. The RL78/F13 MCU reads and processes gear position signals from the RAA2P4500 IPS, which detects shifter position via eddy current principles for high accuracy and durability in harsh environments. The MCU interprets this data and controls actuators or signals the transmission system to ensure reliable gear engagement.
特性
- Low consumption current MCU is designed for automotive applications.
- Inductive position sensor ensures accurate, contactless position detection for precise gear selection.
- Continuous monitoring and built-in fail-safes enhance operational safety and enable quick fault detection.
- Compact design simplifies integration, reducing weight and power consumption.
应用
|
换档器
配备 IPS 和 MCU 的智能换档器可实现精确、耐用和高效的控制。
|
文档
相关文档
请登录后开启订阅
|
|
|
|
|---|---|---|
| 类型 | 文档标题 | 日期 |
| PCB 设计文件 | WS067-GEARSHFT-REFZ Gear Shifter Design Files
The WS067-GEARSHFT-REFZ design files provide the complete hardware materials for the WS067 Gear Shifter Reference Design, including the BOM, circuit schematics, and PCB layout, to support design evaluation, system integration, and customization for development.
|
|
| 手册 - 硬件 | WS067-GEARSHFT-REFZ Gear Shifter Reference Design Manual
The WS067-GEARSHFT-REFZ Gear Shifter Reference Design Manual describes the hardware and software functionality of the design, including system architecture, hardware interfaces, and firmware operation. The kit integrates the RAA2P4500 IPS with the RL78/F13 MCU to enable precise, magnet-free electronic gear position detection for automotive applications. It supports CAN communication and provides a complete solution for development, evaluation, and integration of electronic gear selection systems.
|
|
2 项目
|
||
