RL78/G15 快速原型开发板 (RL78/G15 FPB)
RL78/G15 快速原型开发板配备RL78/G15微控制器，是一种专门用于各种应用开发试产的原型开发板。它只需连接USB线即可编写/调试程序，无需任何其他工具即可着手评估。此外，它还可以使用传统E2仿真器和E2仿真器Lite实现高性能调试（有关方法，请参考用户手册）。标配Arduino...
概览
简介
RL78/G15是一种通用微控制器，工作频率为16MHz。包括RL78系列最小的8引脚封装在内，我们提供丰富的产品阵容，适用于-40℃－125℃的各种工作环境温度。产品内置高精度（±1.0%）高速片上振荡器、数据闪存和丰富的串行接口和比较器，因此适合需要节省空间的小型应用场景。RL78/G15包括丰富的开发环境，只需连接USB线缆, 即可编写和调试评估板（Fast Prototyping Board）、可通过GUI简化软件设计的Smart Configurator和Arduino库等。它与现有的RL78系列兼容，适用于家电、消费类电子产品到工业设备的广泛用途。
特性
- CPU：RL78 内核，最高 16MHz
- 电压：2.4V 到 5.5V
- 封装：8 到 20 引脚
- 闪存：程序闪存：4/8KB，SRAM 1KB，数据闪存 1KB
- 工作温度：不超过 125°C
- 定时器：8 路 16 位定时器，1 路看门狗定时器，1 路 12 位间隔定时器
- 模拟功能：11 路 10 位 A/D 转换器，比较器
- 片上振荡器 (MHz)：高速：1、2、4、8、16MHz；低速：15kHz
- 连接：SCI（CSI、UART、简单版 I2C）、I2C
- 其他：可选通电重置、低电压检测、片上调试 2.4V 到 5.5V（单线、双线）
