概览
描述
The ISL28133A is a single micropower, chopper-stabilized operational amplifier designed for precision and efficiency in compact spaces. With a quiescent current of just 22µA and rail-to-rail input/output, it delivers exceptional performance across a wide supply range of 1.8V to 5.5V. Its ultra-low input offset voltage (10µV max) and minimal noise make it ideal for high-accuracy applications like medical instrumentation, temperature sensing, and electronic weight scales. The device operates across the temperature range of -40°C to +125°C and is available in both an SOT23-5 and SC70-5 packages.
特性
- Single Supply Operation: 1.8V to 5.5V
- Low Input Offset Voltage: ±10µV
- Low Supply Current: 22µA
- Gain Bandwidth Product: 340MHz
- Temperature Range Support: -40°C to +125°C
产品对比
应用
文档
相关文档
请登录后开启订阅
|
|
|
|
|---|---|---|
| 类型 | 文档标题 | 日期 |
| 数据手册 | PDF 1.27 MB | |
| 宣传手册 | PDF 5.41 MB 日本語 | |
| 培训资料 | PDF 162 KB | |
| 应用说明 | PDF 381 KB | |
| 其他 | PDF 519 KB | |
| 应用说明 | PDF 357 KB | |
6 项目
|
||
设计和开发
模型
ECAD 模块
点击产品选项表中的 CAD 模型链接，查找 SamacSys 中的原理图符号、PCB 焊盘布局和 3D CAD 模型。如果符号和模型不可用，可直接在 SamacSys 请求该符号或模型。
