概览
描述
RH850/F1KM-S1 是 RH850/F1x 系列中的一组单芯片微控制器,专为汽车电气车身应用而设计。它实现了低功耗,内部闪存范围为 512KB 至 1MB,封装范围为 48 至 100 引脚。此外,还增加了 CAN FD 接口,CPU 工作频率高达 120MHz。
特性
- 32 位单芯片微控制器,具有一个 G3KH CPU 内核
- 高计算处理能力
- 120MHz 工作频率
- 内部闪存范围为 512KB 到 1MB
- 多种内部外设功能
- CAN FD 接口
- 低功耗
- 低功耗采样器 (LPS) 轮询信号输入,无需 CPU 内核交互
- DeepSTOP 模式可切断芯片内选择电路的电源
- 封装选项范围为 48 到 100 引脚
产品对比
应用
设计和开发
软件与工具
软件与工具
Software title
|
Software type
|
公司
|
---|---|---|
瑞萨 MCAL 瑞萨的 MCAL(微控制器抽象层)软件驱动程序可作为独立软件包获取。
|
Software Package | 瑞萨电子 |
E2 emulator [RTE0T00020KCE00000R] On-chip debugging emulator. Also available as a flash memory programmer. [Support MCU/MPU: RA, RE, RH850, R-Car D1, RL78, RX, RISC-V MCU]
|
Emulator | 瑞萨电子 |
Automotive BMS Application Model & Software BMS application models and software reduce the effort and time required to develop applications to estimate State Of Charge and State Of Health.
|
Software Package | 瑞萨电子 |
Code Flash Libraries (Flash Self Programming Libraries) Libraries for the reprogramming of code area flash memory, including EEPROM emulation libraries for the code areas of 78K-family products
|
Self Programming Library (Flash Library) | 瑞萨电子 |
RH850 Smart Configurator RH850 Smart Configurator is an automatic driver generation tool for internal peripheral I/O modules through GUI settings.
|
Solution Toolkit | 瑞萨电子 |
RH850 基于模型的开发环境 [Embedded Target for RH850 Virtual Platform] Embedded Target for RH850 Virtual Platform是一种开发环境,允许用户从Simulink®模型生成目标设备的外设代码,可在Simulink和虚拟环境中执行协同验证vHILS(Virtual Hardware In the Loop Simulation)。
|
Model-Based Development | 瑞萨电子 |
Data Flash Libraries Libraries for the reprogramming of data flash memory, including EEPROM emulation libraries for the data areas of RL78-family products
|
Self Programming Library (Flash Library) | 瑞萨电子 |
Green Hills Multi 多开发环境:快速开发、调试、测试以及优化嵌入式应用和实时应用。Green Hills 优化编译器:使用 C、C++ 和 Ada 生成最小和最快的代码。
|
IDE and Coding Tool | Green Hills Software LLC |
IAR Embedded Workbench for Renesas RH850 IAR Embedded Workbench 可为 RH850 设备提供广泛支持。 IAR Embedded Workbench 是一套具备领先优化技术的完整开发工具,可用于创建强大的汽车应用程序。
|
IDE and Coding Tool | IAR Systems |
Green Hills MULTI Device-Support-Packages Green Hills MULTI Device-Support-Packages include all device specific files to be used with the MULTI IDE.
|
IDE and Coding Tool | 瑞萨电子 |
Renesas Flash Programmer (Programming GUI) 闪存编程软件【支持 MCU/MPU 和设备:RA、RE、RX、RL78、RH850、RISC-V MCU Renesas Synergy、DA1453x、DA1459x、DA1469x、DA1470x、电源管理、Renesas USB Power Delivery 系列、电机驱动器/执行器驱动器 IC、V850、78K0R、78K0】
|
Programmer (Unit/SW) | 瑞萨电子 |
C Compiler Package for RH850 Family [CC-RH] C Compiler Package for RH850 Family [IDE: CS+, e² studio]
|
Compiler/Assembler | 瑞萨电子 |
12 items
|
样例程序
样例程序
筛选
|
||
---|---|---|
类型 | 文档标题 | 日期 日期 |
示例代码 | ZIP 8.87 MB | |
示例代码 | ZIP 5.54 MB | |
示例代码 |
ZIP
1.29 MB
应用:
云计算和企业, 汽车
Function:
Application Example
IDE:
GHS MULTI for RH850
|
|
示例代码 | ZIP 3.74 MB | |
示例代码 |
ZIP
1.49 MB
应用:
汽车
|
|
示例代码 |
ZIP
1.62 MB
应用:
工业, 消费电子产品
Compiler:
GHS MULTI for V800
Function:
Application Example
IDE:
MULTI
|
|
示例代码 | ZIP 1.55 MB | |
7 items
|
开发板与套件
RH850/F1x, RH850/F1Kx 176-pin Piggyback Board of RH850 Evaluation Platform
The RH850/F1x 176-pin Piggyback Board supports all devices of the RH850/F1L and RH850/F1KM-S1 series in 176-pin package. It can be used standalone or in combination with a mainboard of the RH850 Evaluation Platform. The modular RH850 Evaluation Platform consisting of mainboards and piggyback...
RH850/F1KM-S1 Starter Kit
The ‘RH850/F1KM-S1 Starter Kit’ serves as a simple and easy to use platform for evaluating the features and performance of Renesas Electronics’ 32-bit RH850/F1KM-S1 microcontrollers.
使用 RH850/F1KM-S1 的电机控制入门套件
瑞萨电子 RH850/F1KM-S1 BLDC 入门套件 V2 (Y-BLDC-SK-RH850F1KM-S1-V2) 让工程师能够在使用先进的无传感器磁场定向控制算法驱动三相永磁同步电机 (PMSM) 的同时,轻松地在实验室环境中对 RH850/F1KM-S1 的性能进行测试和评估。 此类解决方案的典型应用包括:压缩机、空调、风扇、抽气机、泵、家用电器逆变器和工业用驱动器。
该套件可以通过使用已安装的编码器和电位器在未连接至 PC 的情况下独立驱动电机。 部分参数也可以显示在 OLED 显示器上(该显示器不包含在套件中)...
RH850/F1x 100pin Piggyback Board of RH850 Evaluation Platform
The RH850/F1x 100pin Piggyback Board supports all devices of the RH850/F1L, RH850/F1K, RH850/F1KM-S1, RH850/F1KM-S2 and RH850/F1KM-S4 series in 100pin-package. It can be used standalone or in combination with a mainboard of the RH850 Evaluation Platform. The modular RH850 Evaluation Platform...
RH850/F1x 48pin Piggyback Board of RH850 Evaluation Platform
The RH850/F1x 48pin Piggyback Board supports all devices of the RH850/F1L and RH850/F1KM-S1 series in 48pin-package. It can be used standalone or in combination with a mainboard of the RH850 Evaluation Platform. The modular RH850 Evaluation Platform consisting of mainboards and piggyback boards...
RH850/F1x 64pin Piggyback Board of RH850 Evaluation Platform
The RH850/F1x 64pin Piggyback Board supports all devices of the RH850/F1L and RH850/F1KM-S1 series in 64pin-package. It can be used standalone or in combination with a mainboard of the RH850 Evaluation Platform. The modular RH850 Evaluation Platform consisting of mainboards and piggyback boards...
RH850/F1x 80pin Piggyback Board of RH850 Evaluation Platform
The RH850/F1x 80pin Piggyback Board supports all devices of the RH850/F1L and RH850/F1KM-S1 series in 80pin-package. It can be used standalone or in combination with a mainboard of the RH850 Evaluation Platform. The modular RH850 Evaluation Platform consisting of mainboards and piggyback boards...
