RA6T2

有效
产品长期供货

240MHz Arm Cortex-M33 TrustZone，适用于电机控制的高实时引擎

立即订购

特性

  • 搭载 TrustZone® 的 240MHz Arm Cortex-M33
  • 256KB -512KB 闪存和具有 ECC 的 64KB SRAM
  • 16KB 数据闪存，提供与 EEPROM 类似的数据存储功能
  • 从 48 引脚至 100 引脚的多种封装
  • 用于电机控制计算的硬件加速器
  • 12 位 ADC
  • 12 位 DAC
  • 可编程增益放大器
  • 高速比较器
  • PWM 定时器
  • CAN FD（可选）
  • SCI 多功能串口（UART、简单 SPI、简单 I2C）
  • 独立的 SPI 接口/I2C 多主接口
查找RA Arm Cortex-M MCU的其他产品
RA6T2 Block Diagram
Renesas' RA6T2 Group MCUs
RA6T2 Block Diagram
RA6T2 Block Diagram
Renesas' RA6T2 Group MCUs

描述

瑞萨 RA6T2 群组是第二款针对电机和逆变器控制解决方案的 RA ASSP 产品。 RA6T2 将 Arm® Cortex®-M33 与用于电机控制的硬件加速器以及用于实现 240MHz 高速实时性能的高速闪存相结合。 它还可以实现下一代高速、高响应电机算法，并提高其他通信处理等并行处理性能。 我们总共有 20 种不同的型号，使用 5 种不同的封装类型。 灵活配置软件包 (FSP) 和 Arm 合作伙伴生态系统确保通过易用解决方案来实现高效精准的电机和逆变器控制。

产品参数

属性值
Main CPUArm Cortex-M33
Program Memory (KB)256, 512
RAM (KB)64
Carrier TypeBulk (Tray), Full Carton (Tray)
Supply Voltage (V)2.7 - 3.6
I/O Ports35, 51, 84
DRAM I/FNo
Temp. Range (°C)Ta=-40 to +105
Operating Freq (Max) (MHz)240
Ethernet speedNo
EtherCat (ch) (#)0
USB FS (host ch/device ch)( 0 / 0 )
USB HS (host ch/device ch)( 0 / 0 )
USB SS (host ch/device ch)( 0 / 0 )
SCI or UART (ch)6
SPI (ch)2
I2C (#)2
CAN (ch)1
CAN-FD (ch)0, 1
WirelessNo
SDHI (ch)0
High Resolution Output TimerYes
PWM Output (pin#)16, 18, 20
32-Bit Timer (ch)10
16-Bit Timer (ch) (#)0
Standby operable timerNo
Asynchronous General Purpose Timer / Interval Timer (ch)2
16-Bit A/D Converter (ch)0, 10, 18, 29
14-Bit A/D Converter (ch)0
12-Bit A/D Converter (ch)10, 18, 29
24-Bit Sigma-Delta A/D Converter (ch)0
12-Bit D/A Converter (ch)2, 4
8-Bit D/A Converter (ch)0
Capacitive Touch Sensing Unit (ch)0
Image CodecNo
Segment LCD ControllerNo
Security & EncryptionUnique ID, TRNG, AES(128/256), GHASH, Arm TrustZone

封装选项

Pkg. TypePkg. Dimensions (mm)Lead Count (#)Pitch (mm)
HWQFN7 x 7 x 0.8480.5
HWQFN8 x 8 x 0.8640.4
LQFP7 x 7 x 1.7480.5
LQFP10 x 10 x 1.7640.5
LQFP14 x 14 x 1.71000.5

应用方框图

Humanoid battery management system block diagram features cell balancing and monitoring, charge and discharge protection, pack voltage and current sensing, battery pack control, communications, auxiliary power, and active cooling.
人形机器人电池管理系统
集成式人形机器人 BMS，可实现安全、实时的功率管理、保护及电池状态控制。
Single-stage DAB-based solar microinverter block diagram leverages an Arm Cortex MCU and GaN bi-directional switch with low on‑state resistance and low switching capacitances.
基于单级 DAB 的太阳能微逆变器
该系统可提供 500W 高密度、高效率的 GaN 基微逆变器功率。
Interactive block diagram of a hybrid inverter with an intermediate DC Bus architecture
混合逆变器
该混合逆变器系统采用混合架构和 MPPT 算法，可实现高效的能源存储。
High-performance dexterous hand block diagram realizes an architecture capable of 17 DOF and features integrated sensors and multiple motor control subsystems.
灵巧型机器人手
适用于可扩展灵巧型机器人手的模块化、高精度电机控制架构。
High-end Ki wireless power transceiver system with GUI block diagram features a TFT‑based capacitive touch interface with integrated Bluetooth LE or Wi‑Fi.
Ki 无线电源收发器系统（Tx）
将感应式电力传输与 NFC 相结合的高能效 Ki 无线电源收发器，为设备充电提供可靠、紧凑、无线的解决方案。
Photovoltaic (PV) Arc Detection System Block Diagram
光伏（PV）电弧检测系统
实时 PV 电弧检测系统能够快速、准确地识别故障，将火灾风险降至最低。
1.2kW High-Voltage Inverter with GaN-based Power Factor Correction (PFC) Block Diagram
1.2kW 高压 GaN 逆变器
采用了基于 GaN 的 PFC 的高效高压 GaN 逆变器，适用于工业电机驱动。
High-Power 10.5kW Motor Control Block Diagram
10.5kW 大功率电机控制
大功率电机控制系统可支持 10.5kW，并具有高效 MCU 管理功能和灵活连接方式。
Grid-connected solar micro inverter block diagram features a 240MHz MCU with high-resolution PWM, MOSFETs, drivers, and optical coupled isolation amplifier.
并网太阳能微型逆变器
太阳能微型逆变器系统，带有高性能MCU、MOSFET和驱动器的并网单元。
400V/2kW Synchronous Motor Controller with HMI Controller Block Diagram
400V/2kW 同步电机控制器，带 HMI 控制器
400V/2kW 同步电机控制器与工业 HMI 控制器和 AC/DC 电源配对。
3.6kW bidirectional digital power PFC system block diagram utilizes a high-performance Arm Cortex MCU designed to support advanced 650V GaN FETs.
数字电力系统
适用于电动汽车、能源和工业应用的高效数字电力系统。
High-Efficiency Online Uninterruptible Power Supply (UPS) with Real-Time Monitoring Block Diagram
具有实时监控功能的高效在线不间断电源（UPS）
在线 UPS 通过实时监控、高级电源管理和效率确保不间断电源。
Absolute Inductive Position Sensor Block Diagram
绝对感应式位置传感器
经济高效的传感器系统采用可定制设计，支持转速高达 250,000 RPM 的电机。
BLDC Traction Motor Drive Block Diagram
BLDC 牵引电机驱动
一款带有三相智能驱动器的高性能 MCU，具有高能效、可编程和传感器集成等特点。
Battery Formation and Testing System Block Diagram
电池化成和测试系统
瑞萨电子的 32 位 MCU 可实现双向电源转换、精确的电池测量和控制。

其他应用

  • 家电（洗衣机、电磁炉、电动工具）
  • 工业（AC 驱动器、AC 伺服电机、机器人）
  • HVAC（供暖设备、空调）

完成您的设计

寻找相关的产品，完善您的设计

DC/DC 转换器
RAA211250
集成 FET 30V、5A 同步降压稳压器，带内部补偿和可编程频率
 数据手册
放大器
READ2304G
高驱动性能、高转换率、全范围输入输出、CMOS 双通道运算放大器，VIO ≤ ±6mV、SR = 8V/μs
 数据手册
功率 MOSFET
RBE024N08R1SZN6
80V, 175A, 2.4mΩ, REXFET-1 N 沟道功率 MOSFET, SO8-FL (5x6)封装
 数据手册
线性稳压器（LDO）
RAA214250
20V、500mA 线性稳压器
 数据手册
光电耦合器（光耦合器）
PS8352AL2
Analog Output Type Optical Coupled Isolation Amplifier
 数据手册
放大器
UPC277G2
General-purpose Comparators Utilizing CMOS Process Suitable for Low Voltage, Low Power Consumption, and Fast Response
 数据手册
光电耦合器（光耦合器）
RV1S9231A
2.5A 输出电流、高 CMR、IGBT 栅极驱动、5-Pin SSOP（LSSO5 具备 8.2mm 爬电距离）光电耦合器
 数据手册
DC/DC 转换器
RAA211820
集成 FET 75V、2A 同步降压稳压器，具有内部补偿和可编程频率
 数据手册
AC/DC 与隔离式 DC/DC 转换器
RAA223181
900V 离线反激式稳压器
 数据手册
RS-485/422、RS-232 和多协议收发器
RAA788158
5V Half-Duplex, 20Mbps RS-485/422 Differential Transceiver with ±5kV EFT Immunity and ±16.5kV ESD Protection
 数据手册
FET 驱动器
HIP2211
100V、3A 拉电流、4A 灌电流高频半桥驱动器，带有 HI/LI 输入
 数据手册
GaN 功率分立器件
TP65H030G4PQS
650V 30mΩ SuperGaN FET 封装 TOLL
 数据手册
感应式位置传感器
IPS2550
适用于高速电机换向的电感式位置传感器（汽车）
 数据手册
DC/DC 转换器
ISL8117
同步降压 PWM 控制器
 数据手册
DC/DC 转换器
ISL85415
宽范围 VIN 500mA 同步降压稳压器
 数据手册
DC/DC 转换器
RAA211605
60V 0.5A DC/DC 降压型稳压器，开关频率为 450kHz
 数据手册
DC/DC 转换器
ISL85003A
Highly Efficient 3A Synchronous Buck Regulator
 数据手册
放大器
ISL28291
Dual Single Supply Ultra-Low Noise, Low Distortion Rail-to-Rail Output, Op Amp
 数据手册
放大器
ISL28134
5V Ultra Low Noise, Zero Drift Rail-to-Rail Precision Op Amp
 数据手册
功率 MOSFET
RBE029N10R1SZN6
100V, 160A, 2.9mΩ, REXFET-1 N 沟道功率 MOSFET, SO8-FL (5x6) 封装
 数据手册
功率 MOSFET
RJK1002DPP-A0
Nch Power MOSFET 100V 70A 7.6mohm TO-220F
 数据手册
功率 MOSFET
RBA300N10EANS-3UA02
100V、340A、1.5mΩ、TOLL、N 沟道、REXFET-1 车规级功率 MOSFET
 数据手册
线性稳压器（LDO）
RAA214220
20V、150mA 线性稳压器
 数据手册
AC/DC 与隔离式 DC/DC 转换器
iW1702
45W 数字 AC/DC PWM 控制器，具有可配置的轻负载工作模式，针对 9V+ 应用进行了优化
 数据手册
AC/DC 与隔离式 DC/DC 转换器
iW1816
AccuSwitch™ 离线数字 PWM 转换器，带 800V 双极性功率晶体管
 数据手册
器件号状态样品供应期限库存封装预算价格（美元）Carrier TypeFamily NameSeries NameGroup NameCPU ArchitectureMain CPUSub CPUFloating Point UnitBit LengthProgram Memory (KB)Data Flash (KB)RAM (KB)ECC SRAMLead Count (#)Pitch (mm)Pkg. Dimensions (mm)Number of Supply Voltage(s) (#)Supply Voltage (V)I/O PortsDMAC or DTCDMA (ch)Temperature Sensor (ch) (#)Power-On ResetWatchdog Timer (ch)External Memory Bus (bit)DRAM I/F3D GPUAcceleratorMOQTemp. Range (°C)External Interrupt Pins (#)LVD or PVDOperating Freq (Max) (MHz)Sub-clock (32.768 kHz)On-chip OscillatorEthernet speedEthernet (ch)EtherCat (ch) (#)USB Ports (#)USB FS (host ch/device ch)USB HS (host ch/device ch)USB SS (host ch/device ch)PCI Express (generation and ch)SCI or UART (ch)SPI (ch)QSPI (ch)OSPI (ch)I2C (#)I3C (ch)CAN (ch)CAN-FD (ch)WirelessIrDALIN (#)SDHI (ch)High Resolution Output TimerPWM Output (pin#)32-Bit Timer (ch)16-Bit Timer (ch) (#)8-Bit Timer (ch)Standby operable timerAsynchronous General Purpose Timer / Interval Timer (ch)RTC16-Bit A/D Converter (ch)14-Bit A/D Converter (ch)12-Bit A/D Converter (ch)10-Bit A/D Converter (ch)24-Bit Sigma-Delta A/D Converter (ch)16-Bit D/A Converter (ch)12-Bit D/A Converter (ch)10-Bit D/A Converter (ch) (#)8-Bit D/A Converter (ch)Analog Comparator (ch)OPAMP (ch) (#)PGA (ch)Capacitive Touch Sensing Unit (ch)Graphics LCD ControllerMIPI Interfaces (DSI) (ch)MIPI Interfaces (CSI) (ch)Camera I/F (Parallel)Image Codec2D Drawing EngineSegment LCD ControllerSSI (ch)Security & EncryptionDebug InterfaceMoisture Sensitivity Level (MSL)Country of AssemblyCountry of Wafer Fabrication
R7FA6T2AB3CFL#AA1ActiveN/ATBD有库存LFQFP1ku | $3.14Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes48#0.5mm7 x 7 x 1.71#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes161000No2No100100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2AB3CFL#BA0ActiveN/ATBD缺货LFQFP1ku | $3.31Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes48#0.5mm7 x 7 x 1.71#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator2000Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes161000No2No00100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2AB3CFL#BA1ActiveAvailable2041 Dec缺货LFQFP1ku | $3.14Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes48#0.5mm7 x 7 x 1.71#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator2000Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes161000No2No100100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2AB3CFM#AA1ActiveN/ATBD有库存LFQFP1ku | $3.29Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes64#0.5mm10 x 10 x 1.71#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes181000No2No180180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2AB3CFM#BA0ActiveN/ATBD有库存LFQFP1ku | $3.46Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes64#0.5mm10 x 10 x 1.71#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1280Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes181000No2No00180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2AB3CFM#BA1ActiveAvailable2041 Dec缺货LFQFP1ku | $3.29Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes64#0.5mm10 x 10 x 1.71#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1280Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes181000No2No180180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2AB3CFP#AA1ActiveN/ATBD有库存LFQFP1ku | $3.64Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes100#0.5mm14 x 14 x 1.71#2.7 - 3.684DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes201000No2No290290004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2AB3CFP#BA0ActiveN/ATBD有库存LFQFP1ku | $3.83Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes100#0.5mm14 x 14 x 1.71#2.7 - 3.684DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator720Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes201000No2No00290004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2AB3CFP#BA1ActiveAvailable2041 Dec缺货LFQFP1ku | $3.64Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes100#0.5mm14 x 14 x 1.71#2.7 - 3.684DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator720Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes201000No2No290290004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2AB3CNB#AA1ActiveN/ATBD有库存HWQFN1ku | $3.29Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes64#0.4mm8 x 8 x 0.81#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes181000No2No180180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3TAIWANTAIWAN
R7FA6T2AB3CNB#BA1ActiveAvailableTBD缺货HWQFN1ku | $3.29Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes64#0.4mm8 x 8 x 0.81#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator2784Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes181000No2No180180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3TAIWANTAIWAN
R7FA6T2AB3CNE#AA1ActiveN/ATBD有库存HWQFN1ku | $3.14Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes48#0.5mm7 x 7 x 0.81#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes161000No2No100100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3TAIWANTAIWAN
R7FA6T2AB3CNE#BA1ActiveAvailableTBD缺货HWQFN1ku | $3.14Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes48#0.5mm7 x 7 x 0.81#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator3328Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes161000No2No100100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3TAIWANTAIWAN
R7FA6T2AD3CFL#AA1ActiveN/ATBD有库存LFQFP1ku | $3.47Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes48#0.5mm7 x 7 x 1.71#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes161000No2No100100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2AD3CFL#BA0ActiveN/ATBD有库存LFQFP1ku | $3.65Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes48#0.5mm7 x 7 x 1.71#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator2000Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes161000No2No00100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2AD3CFL#BA1ActiveAvailable2041 Dec缺货LFQFP1ku | $3.47Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes48#0.5mm7 x 7 x 1.71#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator2000Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes161000No2No100100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2AD3CFM#AA1ActiveN/ATBD有库存LFQFP1ku | $3.62Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes64#0.5mm10 x 10 x 1.71#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes181000No2No180180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2AD3CFM#BA0ActiveN/ATBD有库存LFQFP1ku | $3.81Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes64#0.5mm10 x 10 x 1.71#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1280Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes181000No2No00180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2AD3CFM#BA1ActiveAvailable2041 Dec缺货LFQFP1ku | $3.62Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes64#0.5mm10 x 10 x 1.71#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1280Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes181000No2No180180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2AD3CFP#AA1ActiveN/ATBD有库存LFQFP1ku | $3.97Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes100#0.5mm14 x 14 x 1.71#2.7 - 3.684DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes201000No2No290290004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2AD3CFP#BA0ActiveN/ATBD有库存LFQFP1ku | $4.18Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes100#0.5mm14 x 14 x 1.71#2.7 - 3.684DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator720Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes201000No2No00290004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2AD3CFP#BA1ActiveAvailable2041 Dec缺货LFQFP1ku | $3.97Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes100#0.5mm14 x 14 x 1.71#2.7 - 3.684DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator720Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes201000No2No290290004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2AD3CNB#AA1ActiveN/ATBD有库存HWQFN1ku | $3.62Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes64#0.4mm8 x 8 x 0.81#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes181000No2No180180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3TAIWANTAIWAN
R7FA6T2AD3CNB#BA1ActiveAvailableTBD缺货HWQFN1ku | $3.62Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes64#0.4mm8 x 8 x 0.81#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator2784Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes181000No2No180180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3TAIWANTAIWAN
R7FA6T2AD3CNE#AA1ActiveN/ATBD有库存HWQFN1ku | $3.47Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes48#0.5mm7 x 7 x 0.81#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes161000No2No100100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3TAIWANTAIWAN
R7FA6T2AD3CNE#BA1ActiveAvailableTBD缺货HWQFN1ku | $3.47Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes48#0.5mm7 x 7 x 0.81#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator3328Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#010NoNo00Yes161000No2No100100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3TAIWANTAIWAN
R7FA6T2BB3CFL#AA1ActiveN/ATBD有库存LFQFP1ku | $3.47Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes48#0.5mm7 x 7 x 1.71#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes161000No2No100100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BB3CFL#BA0ActiveN/ATBD有库存LFQFP1ku | $3.65Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes48#0.5mm7 x 7 x 1.71#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator2000Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes161000No2No00100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BB3CFL#BA1ActiveAvailable2041 Dec缺货LFQFP1ku | $3.47Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes48#0.5mm7 x 7 x 1.71#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator2000Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes161000No2No100100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BB3CFM#AA1ActiveN/ATBD有库存LFQFP1ku | $3.62Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes64#0.5mm10 x 10 x 1.71#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes181000No2No180180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BB3CFM#BA0ActiveN/ATBD有库存LFQFP1ku | $3.81Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes64#0.5mm10 x 10 x 1.71#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1280Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes181000No2No00180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BB3CFM#BA1ActiveAvailable2041 Dec缺货LFQFP1ku | $3.62Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes64#0.5mm10 x 10 x 1.71#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1280Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes181000No2No180180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BB3CFP#AA0ActiveAvailableTBD有库存LFQFP1ku | $4.18Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes100#0.5mm14 x 14 x 1.71#2.7 - 3.684DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes201000No2No00290004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BB3CFP#AA1ActiveN/ATBD有库存LFQFP1ku | $3.97Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes100#0.5mm14 x 14 x 1.71#2.7 - 3.684DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes201000No2No290290004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BB3CFP#BA0ActiveN/ATBD有库存LFQFP1ku | $4.18Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes100#0.5mm14 x 14 x 1.71#2.7 - 3.684DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator720Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes201000No2No00290004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BB3CFP#BA1ActiveAvailable2041 Dec缺货LFQFP1ku | $3.97Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes100#0.5mm14 x 14 x 1.71#2.7 - 3.684DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator720Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes201000No2No290290004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BB3CNB#AA1ActiveN/ATBD有库存HWQFN1ku | $3.62Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes64#0.4mm8 x 8 x 0.81#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes181000No2No180180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3TAIWANTAIWAN
R7FA6T2BB3CNB#BA1ActiveAvailableTBD缺货HWQFN1ku | $3.62Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes64#0.4mm8 x 8 x 0.81#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator2784Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes181000No2No180180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3TAIWANTAIWAN
R7FA6T2BB3CNE#AA1ActiveN/ATBD有库存HWQFN1ku | $3.47Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes48#0.5mm7 x 7 x 0.81#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes161000No2No100100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3TAIWANTAIWAN
R7FA6T2BB3CNE#BA1ActiveAvailableTBD缺货HWQFN1ku | $3.47Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32256KB16KB64KBYes48#0.5mm7 x 7 x 0.81#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator3328Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes161000No2No100100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3TAIWANTAIWAN
R7FA6T2BD3CFL#AA1ActiveAvailableTBD有库存LFQFP1ku | $3.8Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes48#0.5mm7 x 7 x 1.71#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes161000No2No100100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BD3CFL#BA0ActiveN/ATBD有库存LFQFP1ku | $4Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes48#0.5mm7 x 7 x 1.71#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator2000Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes161000No2No00100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BD3CFL#BA1ActiveAvailable2041 Dec缺货LFQFP1ku | $3.8Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes48#0.5mm7 x 7 x 1.71#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator2000Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes161000No2No100100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BD3CFM#AA1ActiveAvailableTBD有库存LFQFP1ku | $3.95Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes64#0.5mm10 x 10 x 1.71#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes181000No2No180180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BD3CFM#BA0ActiveN/ATBD有库存LFQFP1ku | $4.16Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes64#0.5mm10 x 10 x 1.71#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1280Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes181000No2No00180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BD3CFM#BA1ActiveAvailable2041 Dec缺货LFQFP1ku | $3.95Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes64#0.5mm10 x 10 x 1.71#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1280Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes181000No2No180180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BD3CFP#AA0ActiveAvailableTBD有库存LFQFP1ku | $4.53Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes100#0.5mm14 x 14 x 1.71#2.7 - 3.684DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes201000No2No00290004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BD3CFP#AA1ActiveAvailableTBD缺货LFQFP1ku | $4.31Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes100#0.5mm14 x 14 x 1.71#2.7 - 3.684DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes201000No2No290290004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BD3CFP#BA0ActiveN/ATBD缺货LFQFP1ku | $4.53Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes100#0.5mm14 x 14 x 1.71#2.7 - 3.684DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator720Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes201000No2No00290004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BD3CFP#BA1ActiveAvailable2041 Dec缺货LFQFP1ku | $4.31Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes100#0.5mm14 x 14 x 1.71#2.7 - 3.684DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator720Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes201000No2No290290004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3CHINATAIWAN
R7FA6T2BD3CNB#AA1ActiveAvailableTBD有库存HWQFN1ku | $3.95Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes64#0.4mm8 x 8 x 0.81#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes181000No2No180180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3TAIWANTAIWAN
R7FA6T2BD3CNB#BA1ActiveAvailableTBD缺货HWQFN1ku | $3.95Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes64#0.4mm8 x 8 x 0.81#2.7 - 3.651DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator2784Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes181000No2No180180004004040No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3TAIWANTAIWAN
R7FA6T2BD3CNE#AA1ActiveAvailableTBD有库存HWQFN1ku | $3.8Bulk (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes48#0.5mm7 x 7 x 0.81#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator1Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes161000No2No100100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3TAIWANTAIWAN
R7FA6T2BD3CNE#BA1ActiveAvailableTBD缺货HWQFN1ku | $3.8Full Carton (Tray)RARA6RA6T2ArmArm Cortex-M33NoSingle32512KB16KB64KBYes48#0.5mm7 x 7 x 0.81#2.7 - 3.635DMAC&DTC81#Yes2NoNoNoTrigonometric function & IIR Filter Accelerator3328Ta=-40 to +10516#Yes240MHzNoYesNo000( 0 / 0 )( 0 / 0 )( 0 / 0 )No62002#011NoNo00Yes161000No2No100100002003030No00NoNoNoNo0Unique ID, TRNG, AES(128/256), GHASH, Arm TrustZoneJTAG/SWD3TAIWANTAIWAN
