特性
- Highest level of computing performance
- Calculation performance of about 5.5 thousand DMIPS
- ECC function indispensable for system’s high reliability
- ECC support for both L1/L2cache, DDR/IF
- 128KB System RAM
- Built-in high-speed interface (USB 3.0, PCI-e, Gbit-Ether)
- Full high-definition H.265 decoder, H.264 decoder/encoder installed
- Equipped with 3DGfx engine Power VR ideal for embedded devices
- Security function for communication, data, and program protection
描述
High processing performance with dual-core Arm® Cortex®-A53 (1.2GHz) CPUs, with 3D graphics and video codec engine.
As a software platform for this product, Renesas provides the Verified Linux Package, which includes the Linux Kernel, middleware drivers, and basic software for this product. The Verified Linux package is verified and provided by Renesas. (For Android™ and other operating systems support, please contact your local sales representative or distributor).
Android is a trademark of Google LLC.
产品参数
| 属性 | 值 |
|---|---|
| CPU Architecture | Arm |
| Main CPU | Cortex-A53 x 2 |
| Program Memory (KB) | 0 |
| RAM (KB) | 128 |
| Carrier Type | Bulk (Tray), Full Carton (Tray) |
| Supply Voltage (V) | - |
| I/O Ports | 132 |
| NPU | No |
| DRAM I/F | DDR3L-1856 (32-bit) |
| 3D GPU | PowerVR GE8300 |
| Temp. Range (°C) | Ta = -40 to +85 |
| Operating Freq (Max) (MHz) | 1200 |
| Ethernet speed | 100M/1G |
| Ethernet (ch) | 1 |
| EtherCat (ch) (#) | 0 |
| USB FS (host ch/device ch) | ( 1 / 1 ) |
| USB HS (host ch/device ch) | ( 1 / 1 ) |
| USB SS (host ch/device ch) | ( 1 / 1 ) |
| PCI Express (generation and ch) | PCIe (Gen.2.0 1Lane) x 1 ch |
| SCI or UART (ch) | 11 |
| SPI (ch) | 4 |
| I2C (#) | 8 |
| CAN (ch) | 0 |
| CAN-FD (ch) | 2 |
| Wireless | No |
| SDHI (ch) | 3 |
| High Resolution Output Timer | No |
| PWM Output (pin#) | 0 |
| 32-Bit Timer (ch) | 19 |
| 16-Bit Timer (ch) (#) | 4 |
| 8-Bit Timer (ch) | 0 |
| Standby operable timer | No |
| Asynchronous General Purpose Timer / Interval Timer (ch) | 0 |
| 16-Bit A/D Converter (ch) | 0 |
| 14-Bit A/D Converter (ch) | 0 |
| 12-Bit A/D Converter (ch) | 0 |
| 10-Bit A/D Converter (ch) | 0 |
| 24-Bit Sigma-Delta A/D Converter (ch) | 0 |
| 16-Bit D/A Converter (ch) | 0 |
| 12-Bit D/A Converter (ch) | 0 |
| 10-Bit D/A Converter (ch) (#) | 0 |
| 8-Bit D/A Converter (ch) | 0 |
| Capacitive Touch Sensing Unit (ch) | 0 |
| Graphics LCD Controller | No |
| MIPI Interfaces (DSI) (ch) | 0 |
| MIPI Interfaces (CSI) (ch) | 1 |
| Image Codec | H.264 enc/dec, H.265 dec |
| Segment LCD Controller | No |
| Security & Encryption | AES,RSA,Hash,TRNG,Arm TrustZone,Secure boot |
封装选项
| Pkg. Type | Pkg. Dimensions (mm) | Lead Count (#) | Pitch (mm) |
|---|---|---|---|
| FCBGA | 21 x 21 x 2.25 | 552 | 0.8 |
应用方框图
|
用于 RZ MPU 的 SMARC SoM
采用 SMARC 2.1 的紧凑型 RZ SoM 配备高速接口、AI、强大的安全性和可扩展性。
|
|
RZ/G2E 电源和时序系统级模块
电源和时序系统级模块（SoM）确保精确的时序和高效的功率分配。
|
|
支持FHD视频的全功能HMI |
