特性
- 48MHz Arm Cortex-M23 内核
- 高达 128KB 闪存和 16KB SRAM
- 4KB 数据闪存（数据存储方式类似于 EEPROM）
- 可从 32 引脚封装扩展至 64 引脚封装
- -40 至 125°C的宽工作温度范围
- 1.6V 至 5.5V 的宽电压范围
- +-1% 高精度、高速片上振荡器
- 32 位通用 PWM 定时器，低功耗异步通用定时器
- 16 位通用 PWM 定时器
- 实时时钟
- 12 位模数转换器
- 温度传感器
- 无晶振 USB FS，USB Type-C 接口
- SCI（UART、简化 SPI、简化 I2C、智能卡接口）
- 低功耗 UART
- I3C 总线
- CAN
- SPI
- SSI（串行音频接口）
- 随机数生成器
- 安全功能
RA2L2 Block Diagram
描述
RA2L2 产品组是 RA 系列的入门级单芯片微控制器，基于 48MHz Arm® Cortex-M23® 内核，具有高达 128KB 的代码闪存以及 16KB SRAM 存储器。 这款产品采用优化的制程和瑞萨电子的低功耗工艺技术，达到业界一流水平的超低功耗 MCU。 RA2L2 产品组支持 1.6 V 至 5.5 V 的宽工作电压范围，具有丰富的串行通信功能，例如 I3C、SSI、低功耗 UART、CAN、无晶振 USB FS 以及 USB Type-C 接口。 RA2L2 可与 RA2L1 产品组、RA2E1 产品组和 RA2A1 产品组引脚和外围设备兼容，特别适用于电池供电应用以及空间有限的应用，以及其他需要高性能和低功耗的系统。
产品参数
| 属性 | 值 |
|---|---|
| Main CPU | Arm Cortex-M23 |
| Program Memory (KB) | 64, 128 |
| RAM (KB) | 16 |
| Carrier Type | Full Carton (Tray), Full Tray (Tray), Tape & Reel |
| Supply Voltage (V) | 1.6 - 5.5 |
| I/O Ports | 24, 38, 54 |
| DRAM I/F | No |
| Temp. Range (°C) | Ta= -40 to +105, Ta= -40 to +125 |
| Operating Freq (Max) (MHz) | 48 |
| Ethernet speed | No |
| EtherCat (ch) (#) | 0 |
| USB FS (host ch/device ch) | ( 0 / 1 ) |
| USB HS (host ch/device ch) | ( 0 / 0 ) |
| USB SS (host ch/device ch) | ( 0 / 0 ) |
| SCI or UART (ch) | 4 |
| SPI (ch) | 1 |
| I2C (#) | 0 |
| CAN (ch) | 1 |
| CAN-FD (ch) | 0 |
| Wireless | No |
| SDHI (ch) | 0 |
| High Resolution Output Timer | No |
| PWM Output (pin#) | 9, 14 |
| 32-Bit Timer (ch) | 1 |
| 16-Bit Timer (ch) (#) | 6 |
| Standby operable timer | Yes |
| Asynchronous General Purpose Timer / Interval Timer (ch) | 2 |
| 16-Bit A/D Converter (ch) | 0 |
| 14-Bit A/D Converter (ch) | 0 |
| 12-Bit A/D Converter (ch) | 10, 13, 17 |
| 24-Bit Sigma-Delta A/D Converter (ch) | 0 |
| 12-Bit D/A Converter (ch) | 0 |
| 8-Bit D/A Converter (ch) | 0 |
| Capacitive Touch Sensing Unit (ch) | 0 |
| Image Codec | No |
| Segment LCD Controller | No |
| Security & Encryption | Unique ID, TRNG |
应用方框图
 | USB-C Platform with Liquid Detection and Debug Access USB‑C system with liquid detection and debug access through a single connector, improving reliability while simplifying development, testing, and manufacturing. |
 | USB 数据记录器 可随时随地高速准确记录指标的低功耗便携式 USB 数据记录器。 |
 | 配备 GNSS 的电子收费系统 ETC 系统自动支付通行费，有效缓解交通拥堵，避免人工收费站造成的延误。 |
 | 游戏键盘 一款高能效、高度集成且设计紧凑的键盘系统，具有可自定义的 RGB 灯光和稳定、低延迟的无线性能。 |
 | 游戏鼠标 一款高能效、高度集成且设计紧凑的鼠标系统，具有可自定义的 RGB 灯光和稳定、低延迟的无线性能。 |
 | 双指针仪表 双指针仪表可以实时显示两个数值，实现快速直观的模拟监测。 |
 | 采用 AnalogPAK 的电流环路通信 AnalogPAK™ 支持 4 至 20mA 电流环路，支持 HART 调制解调器和 FSK 调制。 |
 | 通用型 USB 转换器，支持 USB-UART、USB-I2C、USB-I3C 通过支持 Pmod 的通用 USB 转换器将 UART、SPI、I2C 和 I3C 设备连接到 PC。 |
其他应用
- 音频流设备
- PC 外设
- POS 系统外设
- 通用系统
- 物联网设备
- 工业自动化和传感器
- 消费者应用
- 家电
- 楼宇自动化
- 医疗和保健设备
- 可穿戴设备
完成您的设计
寻找相关的产品，完善您的设计
SLG46880
GreenPAK 可编程混合信号 IC，VDD 范围：2.3-5.5V，28 个 GPIO，4 个 ACMP，I2C，ASM（12 状态），双电源 VDD2 范围：2.3-5.5V
数据手册
SLG47011
AnalogPAK 可编程混合信号矩阵、VDD Range: 1.71-3.6V、14 GPIOs、1 ACMPs、I2C、ADC (14-bit、SAR)、PGA、DAC (12-bit)、MathCore、SPI
数据手册
SLG46827-A
GreenPAK 汽车用可编程混合信号 IC（2 级），VDD 范围：2.3-5.5V，17 个 GPIO，4 个 ACMP，I2C，双电源 VDD2 范围：1.71-5.5V
数据手册
| 器件号 | 状态 | 样品 | Longevity | 库存 | 封装 | 预算价格（美元） | Carrier Type | Family Name | Series Name | Group Name | CPU Architecture | Main CPU | Sub CPU | Floating Point Unit | Bit Length | Program Memory (KB) | Data Flash (KB) | RAM (KB) | ECC SRAM | Lead Count (#) | Pitch (mm) | Pkg. Dimensions (mm) | Number of Supply Voltage(s) (#) | Supply Voltage (V) | I/O Ports | DMAC or DTC | DMA (ch) | Temperature Sensor (ch) (#) | Power-On Reset | Watchdog Timer (ch) | External Memory Bus (bit) | DRAM I/F | 3D GPU | Accelerator | MOQ | Temp. Range (°C) | External Interrupt Pins (#) | LVD or PVD | Operating Freq (Max) (MHz) | Sub-clock (32.768 kHz) | On-chip Oscillator | Ethernet speed | Ethernet (ch) | EtherCat (ch) (#) | USB Ports (#) | USB FS (host ch/device ch) | USB HS (host ch/device ch) | USB SS (host ch/device ch) | PCI Express (generation and ch) | SCI or UART (ch) | SPI (ch) | QSPI (ch) | OSPI (ch) | I2C (#) | I3C (ch) | CAN (ch) | CAN-FD (ch) | Wireless | IrDA | LIN (#) | SDHI (ch) | High Resolution Output Timer | PWM Output (pin#) | 32-Bit Timer (ch) | 16-Bit Timer (ch) (#) | 8-Bit Timer (ch) | Standby operable timer | Asynchronous General Purpose Timer / Interval Timer (ch) | RTC | 16-Bit A/D Converter (ch) | 14-Bit A/D Converter (ch) | 12-Bit A/D Converter (ch) | 10-Bit A/D Converter (ch) | 24-Bit Sigma-Delta A/D Converter (ch) | 16-Bit D/A Converter (ch) | 12-Bit D/A Converter (ch) | 10-Bit D/A Converter (ch) (#) | 8-Bit D/A Converter (ch) | Analog Comparator (ch) | OPAMP (ch) (#) | PGA (ch) | Capacitive Touch Sensing Unit (ch) | Graphics LCD Controller | MIPI Interfaces (DSI) (ch) | MIPI Interfaces (CSI) (ch) | Camera I/F (Parallel) | Image Codec | 2D Drawing Engine | Segment LCD Controller | SSI (ch) | Security & Encryption | Debug Interface | Moisture Sensitivity Level (MSL) | Country of Assembly | Country of Wafer Fabrication |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| R7FA2L2073CFJ#BA0 | Active | Available | 2037 Dec | 缺货 | LQFP | 1ku | $0.94 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 32# | 0.8mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2000 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2073CFJ#HA0 | Active | N/A | 2037 Dec | 缺货 | LQFP | 1ku | $0.94 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 32# | 0.8mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2000 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2073CFJ#UA0 | Active | N/A | 缺货 | LQFP | 1ku | $0.94 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 32# | 0.8mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 250 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN | |
| R7FA2L2073CFL#BA0 | Active | Available | 2037 Dec | 缺货 | LFQFP | 1ku | $1.02 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2000 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2073CFL#HA0 | Active | N/A | 2037 Dec | 缺货 | LFQFP | 1ku | $1.02 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2000 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2073CFL#UA0 | Active | N/A | 缺货 | LFQFP | 1ku | $1.02 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 250 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN | |
| R7FA2L2073CFM#BA0 | Active | Available | 2037 Dec | 缺货 | LFQFP | 1ku | $1.11 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 64# | 0.5mm | 10 x 10 x 1.7 | 1# | 1.6 - 5.5 | 54 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 1280 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 17 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2073CFM#HA0 | Active | N/A | 2037 Dec | 缺货 | LFQFP | 1ku | $1.11 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 64# | 0.5mm | 10 x 10 x 1.7 | 1# | 1.6 - 5.5 | 54 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 1500 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 17 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2073CFM#UA0 | Active | N/A | 缺货 | LFQFP | 1ku | $1.11 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 64# | 0.5mm | 10 x 10 x 1.7 | 1# | 1.6 - 5.5 | 54 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 160 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 17 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN | |
| R7FA2L2073CNE#BA0 | Active | Available | 2037 Dec | 缺货 | HWQFN | 1ku | $1.02 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 0.8 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 3328 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN |
| R7FA2L2073CNE#HA0 | Active | N/A | 2037 Dec | 缺货 | HWQFN | 1ku | $1.02 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 0.8 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2500 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN |
| R7FA2L2073CNE#UA0 | Active | N/A | 缺货 | HWQFN | 1ku | $1.02 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 0.8 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 416 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN | |
| R7FA2L2073CNH#BA0 | Active | Available | 2037 Dec | 缺货 | HWQFN | 1ku | $0.94 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 32# | 0.5mm | 5 x 5 x 0.8 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 3920 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN |
| R7FA2L2073CNH#HA0 | Active | N/A | 2037 Dec | 缺货 | HWQFN | 1ku | $0.94 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 32# | 0.5mm | 5 x 5 x 0.8 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2500 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN |
| R7FA2L2073CNH#UA0 | Active | N/A | 缺货 | HWQFN | 1ku | $0.94 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 32# | 0.5mm | 5 x 5 x 0.8 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 490 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN | |
| R7FA2L2074CFJ#BA0 | Active | Available | 2037 Dec | 缺货 | LQFP | 1ku | $1 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 32# | 0.8mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2000 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2074CFJ#HA0 | Active | N/A | 2037 Dec | 缺货 | LQFP | 1ku | $1 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 32# | 0.8mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2000 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2074CFJ#UA0 | Active | N/A | 缺货 | LQFP | 1ku | $1 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 32# | 0.8mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 250 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN | |
| R7FA2L2074CFL#BA0 | Active | Available | 2037 Dec | 缺货 | LFQFP | 1ku | $1.09 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2000 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2074CFL#HA0 | Active | N/A | 2037 Dec | 缺货 | LFQFP | 1ku | $1.09 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2000 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2074CFL#UA0 | Active | N/A | 缺货 | LFQFP | 1ku | $1.09 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 250 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN | |
| R7FA2L2074CFM#BA0 | Active | Available | 2037 Dec | 缺货 | LFQFP | 1ku | $1.18 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 64# | 0.5mm | 10 x 10 x 1.7 | 1# | 1.6 - 5.5 | 54 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 1280 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 17 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2074CFM#HA0 | Active | N/A | 2037 Dec | 缺货 | LFQFP | 1ku | $1.18 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 64# | 0.5mm | 10 x 10 x 1.7 | 1# | 1.6 - 5.5 | 54 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 1500 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 17 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2074CFM#UA0 | Active | N/A | 缺货 | LFQFP | 1ku | $1.18 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 64# | 0.5mm | 10 x 10 x 1.7 | 1# | 1.6 - 5.5 | 54 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 160 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 17 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN | |
| R7FA2L2074CNE#BA0 | Active | Available | 2037 Dec | 缺货 | HWQFN | 1ku | $1.09 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 0.8 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 3328 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN |
| R7FA2L2074CNE#HA0 | Active | N/A | 2037 Dec | 缺货 | HWQFN | 1ku | $1.09 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 0.8 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2500 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN |
| R7FA2L2074CNE#UA0 | Active | N/A | 缺货 | HWQFN | 1ku | $1.09 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 0.8 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 416 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN | |
| R7FA2L2074CNH#BA0 | Active | Available | 2037 Dec | 缺货 | HWQFN | 1ku | $1 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 32# | 0.5mm | 5 x 5 x 0.8 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 3920 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN |
| R7FA2L2074CNH#HA0 | Active | N/A | 2037 Dec | 缺货 | HWQFN | 1ku | $1 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 32# | 0.5mm | 5 x 5 x 0.8 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2500 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN |
| R7FA2L2074CNH#UA0 | Active | N/A | 缺货 | HWQFN | 1ku | $1 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 64KB | 4KB | 16KB | No | 32# | 0.5mm | 5 x 5 x 0.8 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 490 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN | |
| R7FA2L2093CFJ#BA0 | Active | Available | 2037 Dec | 缺货 | LQFP | 1ku | $1.04 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 32# | 0.8mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2000 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2093CFJ#HA0 | Active | N/A | 2037 Dec | 缺货 | LQFP | 1ku | $1.04 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 32# | 0.8mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2000 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2093CFJ#UA0 | Active | N/A | 缺货 | LQFP | 1ku | $1.04 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 32# | 0.8mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 250 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN | |
| R7FA2L2093CFL#BA0 | Active | Available | 2037 Dec | 缺货 | LFQFP | 1ku | $1.13 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2000 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2093CFL#HA0 | Active | N/A | 2037 Dec | 缺货 | LFQFP | 1ku | $1.13 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2000 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2093CFL#UA0 | Active | N/A | 缺货 | LFQFP | 1ku | $1.13 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 250 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN | |
| R7FA2L2093CFM#BA0 | Active | Available | 2037 Dec | 缺货 | LFQFP | 1ku | $1.21 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 64# | 0.5mm | 10 x 10 x 1.7 | 1# | 1.6 - 5.5 | 54 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 1280 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 17 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2093CFM#HA0 | Active | N/A | 2037 Dec | 缺货 | LFQFP | 1ku | $1.21 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 64# | 0.5mm | 10 x 10 x 1.7 | 1# | 1.6 - 5.5 | 54 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 1500 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 17 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2093CFM#UA0 | Active | N/A | 缺货 | LFQFP | 1ku | $1.21 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 64# | 0.5mm | 10 x 10 x 1.7 | 1# | 1.6 - 5.5 | 54 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 160 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 17 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN | |
| R7FA2L2093CNE#BA0 | Active | Available | 2037 Dec | 缺货 | HWQFN | 1ku | $1.13 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 0.8 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 3328 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN |
| R7FA2L2093CNE#HA0 | Active | N/A | 2037 Dec | 缺货 | HWQFN | 1ku | $1.13 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 0.8 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2500 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN |
| R7FA2L2093CNE#UA0 | Active | N/A | 缺货 | HWQFN | 1ku | $1.13 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 0.8 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 416 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN | |
| R7FA2L2093CNH#BA0 | Active | Available | 2037 Dec | 缺货 | HWQFN | 1ku | $1.04 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 32# | 0.5mm | 5 x 5 x 0.8 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 3920 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN |
| R7FA2L2093CNH#HA0 | Active | N/A | 2037 Dec | 缺货 | HWQFN | 1ku | $1.04 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 32# | 0.5mm | 5 x 5 x 0.8 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2500 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN |
| R7FA2L2093CNH#UA0 | Active | N/A | 缺货 | HWQFN | 1ku | $1.04 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 32# | 0.5mm | 5 x 5 x 0.8 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 490 | Ta= -40 to +105 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN | |
| R7FA2L2094CFJ#BA0 | Active | Available | 2037 Dec | 缺货 | LQFP | 1ku | $1.12 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 32# | 0.8mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2000 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2094CFJ#HA0 | Active | N/A | 2037 Dec | 缺货 | LQFP | 1ku | $1.12 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 32# | 0.8mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2000 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2094CFJ#UA0 | Active | N/A | 有库存 | LQFP | 1ku | $1.12 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 32# | 0.8mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 250 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN | |
| R7FA2L2094CFL#BA0 | Active | Available | 2037 Dec | 缺货 | LFQFP | 1ku | $1.2 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2000 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2094CFL#HA0 | Active | N/A | 2037 Dec | 缺货 | LFQFP | 1ku | $1.2 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2000 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2094CFL#UA0 | Active | N/A | 有库存 | LFQFP | 1ku | $1.2 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 1.7 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 250 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN | |
| R7FA2L2094CFM#BA0 | Active | Available | 2037 Dec | 缺货 | LFQFP | 1ku | $1.29 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 64# | 0.5mm | 10 x 10 x 1.7 | 1# | 1.6 - 5.5 | 54 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 1280 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 17 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2094CFM#HA0 | Active | N/A | 2037 Dec | 缺货 | LFQFP | 1ku | $1.29 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 64# | 0.5mm | 10 x 10 x 1.7 | 1# | 1.6 - 5.5 | 54 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 1500 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 17 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN |
| R7FA2L2094CFM#UA0 | Active | N/A | 缺货 | LFQFP | 1ku | $1.29 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 64# | 0.5mm | 10 x 10 x 1.7 | 1# | 1.6 - 5.5 | 54 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 160 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 17 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | CHINA | JAPAN | |
| R7FA2L2094CNE#BA0 | Active | Available | 2037 Dec | 缺货 | HWQFN | 1ku | $1.2 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 0.8 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 3328 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN |
| R7FA2L2094CNE#HA0 | Active | N/A | 2037 Dec | 缺货 | HWQFN | 1ku | $1.2 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 0.8 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2500 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN |
| R7FA2L2094CNE#UA0 | Active | N/A | 有库存 | HWQFN | 1ku | $1.2 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 48# | 0.5mm | 7 x 7 x 0.8 | 1# | 1.6 - 5.5 | 38 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 416 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 14 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 13 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN | |
| R7FA2L2094CNH#BA0 | Active | Available | 2037 Dec | 缺货 | HWQFN | 1ku | $1.12 | Full Carton (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 32# | 0.5mm | 5 x 5 x 0.8 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 3920 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN |
| R7FA2L2094CNH#HA0 | Active | N/A | 2037 Dec | 缺货 | HWQFN | 1ku | $1.12 | Tape & Reel | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 32# | 0.5mm | 5 x 5 x 0.8 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 2500 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN |
| R7FA2L2094CNH#UA0 | Active | N/A | 有库存 | HWQFN | 1ku | $1.12 | Full Tray (Tray) | RA | RA2 | RA2L2 | Arm | Arm Cortex-M23 | No | No | 32 | 128KB | 4KB | 16KB | No | 32# | 0.5mm | 5 x 5 x 0.8 | 1# | 1.6 - 5.5 | 24 | DTC | 0 | 1# | Yes | 2 | No | No | No | No | 490 | Ta= -40 to +125 | 8# | Yes | 48MHz | Yes | Yes | No | 0 | 0 | 1# | ( 0 / 1 ) | ( 0 / 0 ) | ( 0 / 0 ) | No | 4 | 1 | 0 | 0 | 0 | 1 | 1 | 0 | No | No | 0 | 0 | No | 9 | 1 | 6# | 0 | Yes | 2 | Yes | 0 | 0 | 10 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | No | 0 | 0 | No | No | No | No | 1ch | Unique ID, TRNG | SWD | 3 | TAIWAN | JAPAN |
